Kern PNS 600-3 precision balance 620 g / 0.001 g
€747.00
% Manufacturer's RRP: €830.00 10% below manufacturer's RRP
- Weighing range 620 g, readability 0.001 g
- Reproducibility 0.001 g, linearity ± 0.004 g, stabilisation time 3 s
- USP minimum sample weight 2 g, weighing pan Ø 140 mm
- Tuning fork weighing system, CAL adjustment programme with external weight
- Glass draught shield with three sliding doors, weighing chamber 172 x 171 x 160 mm
- Capacity display, piece counting, RS-232 as standard, working protective cover in the scope of delivery
ⓘ This product description has been translated from German using AI. Despite careful review, we do not guarantee that the translation is error-free; in case of doubt, the German version shall prevail.
Product information "Kern PNS 600-3 precision balance 620 g / 0.001 g"
The Kern PNS is a precision balance with a tuning fork weighing system, adjusted with an external weight. Three models are available: the PNS 600-3 weighs up to 620 g at 0.001 g (1 mg), the PNS 3000-2 up to 3,200 g at 0.01 g and the PNS 12000-1 up to 12,000 g at 0.1 g. All have a stabilisation time of 3 s, an LCD with 16.5 mm high digits, a stainless steel weighing plate and an RS-232 interface. The PNS 600-3 also features a large glass draught shield.
External adjustment
The CAL adjustment programme adjusts the accuracy of the balance with an external test weight; suitable test weights are available at extra cost. The PNJ series, on the other hand, features internal adjustment and an optional conformity assessment. This does not replace a calibration certificate, which is available separately (see below).
Tuning fork system, counting and capacity display
According to Kern, the tuning fork system displays the weight reading quickly and is mechanically robust. A capacity display shows as a rising bar how much of the weighing range is still free. For piece counting, the reference piece counts 10, 30, 50 and 100 are available; the automatic reference optimisation gradually improves the average value of the unit weight. Depending on the model, the minimum unit weight ranges from 1 mg to 100 mg under laboratory conditions and from 10 mg to 1 g under standard conditions (model table). Additional features include percentage determination, weighing with a tolerance range (visual signal), switchable units and GLP/ISO logging with value and time. According to the data sheet, operation is via a symbol language.
Design
The PNS 3000-2 and PNS 12000-1 are flat with a housing height of 89 mm and have a weighing pan of 190 x 190 mm. They weigh approximately 2.8 kg. The PNS 600-3 has a round weighing pan with a diameter of 140 mm and a glass draught shield with three sliding doors. The weighing chamber measures 172 x 171 x 160 mm (W x D x H); the balance is 266 mm high and weighs approximately 2.2 kg. The plastic housing has a footprint of 196 x 293 mm. The plug-in mains adaptor operates at 220 V to 240 V AC at 50 Hz and comes with country adaptors for EU, AUS, UK, US and CH. The ambient temperature may be between 5 °C and 40 °C, the humidity up to 80 %.
Typical applications
- Pharmacies: weighing with percentage determination and piece counting
- Quality control: weighing with a tolerance range and counting parts
- Electronics and precision engineering industries: counting and weighing small components
- Laboratory applications: weighing of samples and chemicals
- Dental laboratories: weighing quantities of materials
The PNS 600-3 is the model for weighing in to 1 mg with a compact footprint. Anyone weighing quantities up to 3,200 g at 0.01 g takes the PNS 3000-2, for containers up to 12,000 g the PNS 12000-1.
Models at a glance
| Model | Weighing range (Max) | Readability (d) | Reproducibility | Linearity | Stabilisation time | Weighing pan | USP minimum sample weight (k = 2, U = 0.1 %) | Minimum unit weight when piece counting (laboratory / normal) | Net weight approx. |
|---|---|---|---|---|---|---|---|---|---|
| PNS 600-3 | 620 g | 0.001 g | 0.001 g | ± 0.004 g | 3 s | Ø 140 mm | 2 g | 1 mg / 10 mg | 2.2 kg |
| PNS 3000-2 | 3,200 g | 0.01 g | 0.01 g | ± 0.02 g | 3 s | 190 x 190 mm | 20 g | 10 mg / 100 mg | 2.8 kg |
| PNS 12000-1 | 12,000 g | 0.1 g | 0.1 g | ± 0.2 g | 3 s | 190 x 190 mm | 200 g | 100 mg / 1 g | 2.8 kg |
Technical details
These values apply to all models. Deviating values are given in the model table.
| Weighing system | Tuning fork |
| Weighing plate | Stainless steel |
| Housing | Plastic, 196 x 293 x 89 mm (PNS 600-3 with draught shield: height 266 mm) |
| Display | LCD, digit height 16.5 mm, symbol language |
| Units | including g, lb, oz; ct for PNS 600-3 and 3000-2 |
| Reference piece counts when counting | 10, 30, 50, 100 |
| Adjustment | external, CAL adjustment programme, test weights at extra cost |
| Interface | RS-232 as standard |
| Power supply | Plug-in mains adaptor, 220 V to 240 V AC, 50 Hz, with country adaptors for EU, AUS, UK, US and CH |
| Ambient temperature | 5 °C to 40 °C |
| Humidity | up to 80 % |
| DAkkS calibration certificate | can be ordered separately, item no. 963-103, 963-127 or 963-128 depending on the model |
| Warranty (manufacturer) | 36 months according to Kern, excluding wear parts |
Scope of delivery
- Kern PNS precision balance with stainless steel weighing plate
- Glass draught shield with three sliding doors (PNS 600-3 only)
- Working protective cover
- Plug-in mains adaptor with country adaptors for EU, AUS, UK, US and CH
Calibration
A DAkkS calibration certificate can be ordered separately: item no. 963-103 for PNS 600-3, item no. 963-127 for PNS 3000-2, item no. 963-128 for PNS 12000-1. The confirmation of manufacturer specification (969-517) is only available in conjunction with the DAkkS calibration certificate.
Warranty
According to Kern & Sohn, these devices come with a 3-year warranty. Kern grants 3 years on products with a list price of €500 or more and 2 years on products below that and on components; wear parts such as batteries and rechargeable batteries are excluded. Warranty repairs are carried out by Kern or by a Kern dealer.
Downloads
Regulatory information
As electrical devices, the balances fall under the ElektroG. The manufacturer Kern & Sohn GmbH is registered under the WEEE registration number DE 80821200. How to return old appliances is described on the page Environment and disposal.
Individual requirements and procurement service
Working protective covers (PNJ-A01, PNJ-A01S05 with 5 pieces), anti-vibration table (YPS-03), anti-vibration plates (YPS-04, YPS-05), thermal printers (YKC-01, YKH-01), dot-matrix printer (YKG-01), needle printer (YKT-01), RS232 Bluetooth adapter (YKI-02), RS232 Ethernet converters (YKI-10, YKI-11), RS232 WLAN converter (YKI-12) and the RS-232 interface cable (MLB-A05) are also available. For the PNS 600-3, Kern also lists the Safety Set 315-109-206 with the weights 50 g (F1) and 500 g (E2). Enquiries are handled via our procurement service.
| Weighing range (Max): | 620 g |
|---|---|
| Readability (d): | 0.001 g |
| Verifiable: | no |
| Design: | PNS 600-3 · 620 g |
| Power supply: | Mains operation |
