Kern PNJ 12000-1M precision balance 12,000 g / 0.1 g, optional with conformity assessment
€792.00
% Manufacturer's RRP: €880.00 10% below manufacturer's RRP
- Weighing range 12,000 g, readability 0.1 g
- Reproducibility 0.1 g, linearity ± 0.2 g, stabilisation time 3 s
- Tuning fork weighing system, internal adjustment, stainless steel platform 190 x 190 mm
- Conformity assessment under NAWI (2014/31/EU) optional ex works, item no. 965-217, e = 1 g, class II
- Capacity display, piece counting, percentage determination, weighing with tolerance range
- RS-232 as standard, flat design 89 mm, working protective cover in the scope of delivery
Product information "Kern PNJ 12000-1M precision balance 12,000 g / 0.1 g, optional with conformity assessment"
The Kern PNJ 12000-1M is a precision balance with a tuning fork weighing system for weighing up to 12,000 g. It reads to 0.1 g, and the stabilisation time is 3 s. The stainless steel platform measures 190 x 190 mm, and the plastic housing measures 196 x 293 x 89 mm. A conformity assessment under the NAWI Directive (2014/31/EU) is optional and available ex works only. The verification value is then e = 1 g, the accuracy class is II, and the minimum load is 5 g.
Tuning fork weighing system and internal adjustment
According to Kern, the tuning fork system displays the weight reading quickly and is mechanically robust. According to the data sheet, the balance adjusts itself automatically using an internal weight. This does not replace a calibration certificate, which is available separately (see below). Reproducibility is 0.1 g, linearity ± 0.2 g and USP minimum sample weight 200 g.
Display, counting and checking
The LCD has 16.5 mm high digits; according to the data sheet, operation is via a symbol language. A capacity display shows as a rising bar how much of the weighing range is still free. For piece counting, the reference piece counts are 10, 30, 50 and 100. The automatic reference optimisation gradually improves the average value of the unit weight. The minimum unit weight is 100 mg under laboratory conditions and 1 g under standard conditions. In addition, there are percentage determination, weighing with tolerance range (visual signal) and switchable units, including g, lb and oz. The GLP/ISO logging outputs value and time via the standard RS-232 interface.
Compact design
At 89 mm high, the balance is flat and weighs about 3.8 kg. Kern describes the compact dimensions as advantageous in limited space and the stainless steel weighing plate as large and shock-resistant. The plug-in mains adaptor operates at 220 V to 240 V AC at 50 Hz and comes with country adaptors for EU, AUS, UK, US and CH. The ambient temperature may be between 5 °C and 40 °C, the humidity up to 80 %.
Typical applications
- Pharmacies: weighing with percentage determination and piece counting
- Quality control: piece counting and weighing with a tolerance range
- Electronics and precision engineering industries: weighing and counting components
- Laboratory applications: weighing of samples and chemicals up to 12,000 g
- Dental laboratories: weighing quantities of materials
Anyone who needs a weighing subject to mandatory verification should order the conformity assessment together with the balance, because according to Kern a subsequent conformity assessment is not possible. Without this option, the PNJ is a precision balance for everyday laboratory use up to 12,000 g.
Technical details
| Weighing range (Max) | 12,000 g |
| Readability (d) | 0.1 g |
| Reproducibility | 0.1 g |
| Linearity | ± 0.2 g |
| Stabilisation time | 3 s |
| USP minimum sample weight (k = 2, U = 0.1 %) | 200 g |
| Verification value (e) for conformity assessment | 1 g |
| Accuracy class for conformity assessment | II |
| Minimum load (Min) | 5 g |
| Minimum unit weight when piece counting (laboratory / normal) | 100 mg / 1 g |
| Reference piece counts when counting | 10, 30, 50, 100 |
| Weighing system | Tuning fork |
| Weighing plate | Stainless steel, 190 x 190 mm |
| Housing | Plastic, 196 x 293 x 89 mm (W x D x H) |
| Display | LCD, digit height 16.5 mm, symbol language |
| Units | including g, lb, oz |
| Internal adjustment | with internal weight, automatic |
| Interface | RS-232 as standard |
| Power supply | Plug-in mains adaptor, 220 V to 240 V AC, 50 Hz, with country adaptors for EU, AUS, UK, US and CH |
| Net weight | approx. 3.8 kg |
| Ambient temperature | 5 °C to 40 °C |
| Humidity | up to 80 % |
| Conformity assessment under NAWI (2014/31/EU) | optional ex works, item no. 965-217 |
| DAkkS calibration certificate | can be ordered separately, item no. 963-128 |
| Warranty (manufacturer) | 36 months according to Kern, excluding wear parts |
Scope of delivery
- Kern PNJ 12000-1M precision balance with stainless steel weighing plate
- Working protective cover
- Plug-in mains adaptor with country adaptors for EU, AUS, UK, US and CH
Conformity assessment and calibration
A conformity assessment under the NAWI Directive (2014/31/EU) is optional (item no. 965-217). It can only be ordered ex works together with the balance; according to Kern, a subsequent conformity assessment is not possible. To place an order, Kern needs the full address of the installation site. A DAkkS calibration certificate (item no. 963-128) can be ordered separately. The confirmation of manufacturer specification (969-517) is only available in conjunction with the DAkkS calibration certificate.
Warranty
According to Kern & Sohn, this device comes with a 3-year warranty. Kern grants 3 years on products with a list price of €500 or more and 2 years on products below that and on components; wear parts such as batteries and rechargeable batteries are excluded. Warranty repairs are carried out by Kern or by a Kern dealer.
Downloads
Regulatory information
As an electrical device, the balance falls under the ElektroG. The manufacturer Kern & Sohn GmbH is registered under the WEEE registration number DE 80821200. How to return old appliances is described on the page Environment and disposal.
Individual requirements and procurement service
Working protective covers (PNJ-A01, PNJ-A01S05 with 5 pieces), anti-vibration table (YPS-03), anti-vibration plates (YPS-04, YPS-05), thermal printers (YKC-01, YKH-01), dot-matrix printer (YKG-01), needle printer (YKT-01), RS232 Bluetooth adapter (YKI-02), RS232 Ethernet converters (YKI-10, YKI-11), RS232 WLAN converter (YKI-12) and the RS-232 interface cable (MLB-A05) are also available. Enquiries are handled via our procurement service.
| Weighing range (Max): | 12 kg |
|---|---|
| Readability (d): | 0.1 g |
| Verifiable: | yes |
| Power supply: | Mains operation |
