Liebherr FFPSvh 1402 Freezer Storage Cabinet, Double Door, GN 2/1, 1,096 l net capacity, 994490851

If large quantities of frozen goods are regularly handled in a commercial kitchen or catering business, more than just a standard freezer is required, particularly if the goods are pre-portioned and temporarily stored in Gastronorm containers. With a net capacity of 1,096 litres and two fixed stainless-steel doors, the Liebherr FFPSvh 1402 freezer cabinet offers enough space to meet the needs of an entire shift. The housing, doors and internal containers are made entirely from chrome-nickel steel (1.4301 / AISI 304); as the successor to the GGPv 1490 model, the FFPSvh 1402 continues Liebherr’s Perfection series.

Capacity for large kitchens

With external dimensions of 211.5 x 142.7 x 86.7 cm (H x W x D) and an internal space of 151.2 x 123.9 x 65.0 cm, the cabinet offers sufficient capacity to cope with peak times in institutional catering without any restocking issues. Eight storage shelves, all height-adjustable, can be flexibly adapted to accommodate freezer containers of various sizes. In addition, a GN 2/1 longitudinal drawer measuring 530 x 650 mm is provided, allowing standard Gastronorm containers to be stored directly without the need to transfer or temporarily store the contents.

Technology and energy efficiency

The temperature range extends from -9 °C to -26 °C, with a digital display on the outside. In the event of a fault, the unit emits visual and audible warnings. R 290 is used as the refrigerant (fill quantity 104 g), and defrosting is automatic. According to the manufacturer’s specifications, energy consumption is 6,049 kWh per 24 hours or 2,208 kWh per year; the EPREL registration number 1936933 verifies these figures. The connectivity solution is already integrated and removable, and a Wi-Fi/LAN interface is included as standard. Five height-adjustable feet (115 to 175 mm) compensate for uneven floors, making installation easier even in older kitchen buildings with uneven tiled floors.

Features and hygiene

Both doors feature a handle strip and are fixed in position (left fixed/right fixed); they are locked mechanically. A double-sided LED light strip ensures a clear view of the interior, even when only one of the two doors is open. The housing, made entirely of chrome-nickel steel, is resistant to the harsh cleaning agents commonly used in professional kitchens and can be wiped down with minimal seams. This simplifies daily cleaning as well as regular disinfection as part of an HACCP programme – a significant time-saving advantage, particularly for an appliance of this size.

Connection and Specifications

The appliance is connected to a 220–240 V supply with a connected load of 4.0 A; the 3-metre-long power cable covers even longer distances to the nearest socket. With a gross weight of 225.00 kg and a packaging height of 222.0 cm, the route to the installation site should be planned in advance, paying particular attention to door widths and stairs. The FFPSvh 1402 is manufactured at the Liebherr plant in Lienz, as are the other models in the Perfection series for professional kitchen use.

Typical areas of application

The FFPSvh 1402 is designed for high-volume goods handling:

• Centralised frozen food storage in commercial kitchens and canteens
• Stock management for catering businesses with high stock turnover
• Storage of GN containers with pre-portioned frozen goods
• Additional capacity in hotel kitchens during seasonal peak periods
• Central warehouse for chain stores in the food retail sector

Technical details

Energy efficiency

An official EU energy label is available for this appliance. The energy label for this appliance follows the scale from A+++ to E. You can request the full label and the product data sheet from us.

Contents

• 1x Liebherr FFPSvh 1402 freezer cabinet
• User manual
