Macherey-Nagel QUANTOFIX Relax Test Strip Reader, 91346
€671.25
% Regular price: €895.00 (25% saved)
- Reflectometer for objective analysis of QUANTOFIX and pH-Fix test strips
- No special strips required – standard test strips can be used
- Automatic self-calibration
- Up to 50 strips per hour
- Built-in thermal printer
- Data memory for 200 measurements
- Mains or battery operation (6 AA), 2-year warranty
Product information "Macherey-Nagel QUANTOFIX Relax Test Strip Reader, 91346"
Test strips are quick and easy to use – but visual interpretation remains subjective. The QUANTOFIX Relax from Macherey-Nagel solves precisely this problem: it objectively analyses standard QUANTOFIX and pH-Fix test strips using a reflectometer, thereby combining the simplicity of the test strip method with the reliability of instrumental analysis.
Objective analysis without special strips
The QUANTOFIX Relax does not require specialised strips, but reads standard pH-Fix and QUANTOFIX test strips. As a microprocessor-controlled reflectometer, it features self-testing and auto-calibration – calibration takes place automatically and independently, without the need for manual adjustment. Up to 50 strips per hour can be analysed.
Operation & Documentation
Operation is via an LCD display with a touchscreen and alphanumeric input. Results can be printed directly via the integrated thermal printer or processed further via the RS232, USB B (host) and PS/2 (for keyboard or barcode scanner) interfaces. The internal memory holds 200 measurements; software updates are available free of charge via the internet/PC.
Compact & versatile
Measuring 200 x 160 x 75 mm and weighing just 0.71 kg, the device is equally suited to mobile use in the field and to a fixed laboratory workstation. It is powered by 100–240 V AC, or optionally by 6 AA batteries – handy for use without a mains connection.
Technical details
| Type | Microprocessor-controlled reflectometer with self-test and auto-calibration |
| Calibration | Automatic, self-calibrating |
| Strips per hour | 50 |
| Display | LCD display with touchscreen |
| Operation | Alphanumeric input via touchscreen |
| Data storage | 200 measurements |
| Interfaces | RS232, USB B (host), PS/2 for connecting a keyboard or barcode scanner |
| Further information | Built-in thermal printer |
| Update | Free via the internet / PC |
| Language | DE / EN / FR / ES / IT / PT / PL / TR / HU |
| Power supply | 100–240 V AC, optionally with 6 AA batteries |
| Operating range | 10–40 °C, max. 80% relative humidity (non-condensing) |
| Dimensions (L x W x H) | 200 x 160 x 75 mm |
| Weight | 0.71 kg |
| Gross weight (including packaging) | 1650 g |
| Packaging dimensions | 230 x 320 x 170 mm |
| Hazardous substances | No |
| Warranty | 2 years |
| Trademark | QUANTOFIX |
| Contents | QUANTOFIX Relax, power supply unit, adapter plug, user manual, 1 roll of printer paper and certificate |
