Restek Rxi-17Sil MS GC Capillary Column, 30 m, 0.25 mm ID, 0.25 µm, 14123
€795.00
% Manufacturer's RRP: €883.00 9% below manufacturer's RRP
- Rxi-17Sil MS in 30 m, 0.25 mm ID and 0.25 µm film
- Phase of medium polarity, crosslinked
- 40 °C to 340 °C isothermal, 360 °C programmed
- For active environmental compounds such as PAHs
- For detectors such as MS
Product information "Restek Rxi-17Sil MS GC Capillary Column, 30 m, 0.25 mm ID, 0.25 µm, 14123"
At 30 m length, 0.25 mm inner diameter and 0.25 µm film thickness, the Rxi-17Sil MS 14123 is the longer of the two Rxi-17Sil MS columns in the shop. It is one of the crosslinked phases of medium polarity and is intended for active environmental compounds such as PAHs and for MS detectors.
About the phase
Rxi-17Sil MS is characterised by high inertness and selectivity as well as low column bleed. The polarity is intermediate, and the USP phase class is G3. The tube material is fused silica, and the phase is crosslinked.
Agilent DB-17ms, Phenomenex ZB-50 and Quadrex 007-17MS are comparable phases. Comparable part numbers are Agilent 122-4732 and CP8982 as well as Phenomenex 7HG-G004-11.
Temperatures
Usable from 40 °C, and starting conditions have to be set accordingly. Upwards, 340 °C isothermal and 360 °C in a temperature program are permitted. This applies equally to both lengths of the Rxi-17Sil MS, including the value 40 °C as the lower limit.
Notes on the dimensions
This column measures 30 m in length, 0.25 mm in inner diameter and carries a phase film 0.25 µm thick. Crosslinked means that the polymer chains of the phase are linked. Isothermal and programmed distinguish the two upper limits: constant oven temperature versus a temperature program.
Choosing the length
The counterpart 14120 has a length of 15 m with the same diameter and film thickness, and this column has twice that. Retention times shift when the length changes, so the method has to be re-checked afterwards.
| Part number | Length | Inner diameter | Film thickness | Difference to this column |
|---|---|---|---|---|
| 14120 | 15 m | 0.25 mm | 0.25 µm | -15 m |
Typical applications
The column is intended for active environmental compounds such as PAHs. In addition there is use with sensitive detectors such as MS. The assignment applies to both lengths of the family.
Technical details
| Part number | 14123 |
|---|---|
| Product line | Rxi GC columns |
| Phase | Rxi-17Sil MS |
| Phase composition | Crosslinked phase of medium polarity |
| Polarity | Intermediate |
| Length | 30 m |
| Inner diameter | 0.25 mm |
| Film thickness | 0.25 µm |
| Column material | Fused silica |
| Lower temperature limit | 40 °C |
| Upper temperature limit isothermal | 340 °C |
| Upper temperature limit programmed | 360 °C |
| USP phase class | G3 |
| Comparable phases from other manufacturers | Agilent DB-17ms, Phenomenex ZB-50, Quadrex 007-17MS |
| Comparable part numbers from other manufacturers | Agilent 122-4732, Agilent CP8982, Phenomenex 7HG-G004-11 |
| Applications | Active environmental compounds such as PAHs, use with sensitive detectors such as MS |
| Pack contents | 1 piece (single column) |
Scope of delivery
One capillary column (single piece) with a length of 30 m is supplied. Part number 14123 defines length, inner diameter and film thickness.
Individual requirements and procurement service
Further dimensions of the Rxi-17Sil MS, other phases and accessories are part of the Restek range. We procure them on request and also take the Restek part number as a basis. Write to us with what you need, ideally with the part number or with phase, length, inner diameter and film thickness. Then we will get back to you with a quote.
