IKA AD 25 Mounting support, mounting bracket for DK 25.11, 0002562500

ⓘ  This product description has been translated from German using AI. Despite careful review, we do not guarantee that the translation is error-free; in case of doubt, the German version shall prevail.

Product information "IKA AD 25 Mounting support, mounting bracket for DK 25.11, 0002562500"

Stability for your in-line processes: the IKA AD 25 mounting support

In process-related sample preparation, particularly during continuous in-line dispersion at pilot or production scale, high physical forces are at work. When a high-performance disperser is operated at speeds of up to 25,000 revolutions per minute to produce viscous emulsions or fine suspensions, vibrations and torsional forces can arise. This is particularly true when the system is integrated into a closed pump circuit under pressure or vacuum. The heavy flow-through chamber (such as the IKA DK 25.11) be left ‘suspended’ from the drive motor. Imbalance or vibration can stress the mechanical seals of the dispersing tool. To absorb this mechanical stress and support operational safety, the IKA AD 25 Mounting support (MPN 0002562500) is the important component in your setup. This mounting bracket is used to lock your flow-through chamber in place on a stable stand system.

The foundation of the UTL 25 inline system

The IKA AD 25 Mounting support is a component that serves as the mounting for the UTL 25 digital Inline ULTRA-TURRAX system. This complete system typically consists of the dispersion drive, the special, vacuum-tight inline dispersion tools (such as the S 25 KV - 25 G - IL or S 25 KV - 25 F - IL), the DK 25.11 flow-through chamber and a robust floor-standing or telescopic stand (such as the R 6547 H floor stand). The AD 25 mounting bracket encloses the flow-through chamber with a precise fit and connects it rigidly to the stand. Thanks to this rigid, mechanical three-point connection (stand, mounting bracket, chamber), the drive motor (for example, the T 25 digital) is relieved of the dead weight of the chamber, which is completely filled with liquid, as well as the dynamic flow forces from the connected hose lines.

Bearing wear

One aspect that is very often underestimated when setting up in-line dispersion systems is the micrometre-precise axial alignment of all system components. If the flow-through chamber and the dispersing tool rotating within it are not aligned, this results in asymmetrical pressure on the sensitive PTFE or FFKM mechanical seals, as well as on the internal ball bearings of the tool shaft. The consequence can be increased wear, which shortens the service life of the dispersing tools. The AD 25 Mounting support holds the system in a rigid position. This can reduce the mechanical load inside the tool.

Occupational Health and Safety

In addition to the purely mechanical protection it offers the system, the IKA AD 25 Mounting support can contribute to occupational health and safety. In-line dispersers are frequently integrated into strictly regulated, closed circuits in which hazardous organic solvents, highly heated oils or toxic active pharmaceutical ingredients (APIs) circulate under high pressure. An accidental slip, unnoticed material fatigue caused by uncontrolled vibrations, or even the detachment of hose connections due to severe pump surges can have consequences for laboratory staff, the environment and the entire plant. The design of the AD 25 Mounting support is intended to reduce these risks. It fixes the flow-through chamber to the stand.

Material quality and ergonomics

The mounting support is designed for everyday use in laboratories and pilot plants. The locking mechanism can be released for cleaning, maintenance or changeover work.

Technical data

  • Primary function: Rigid, vibration-free mounting bracket for flow-through chambers
  • Compatible flow-through chamber: Precisely designed to fit the IKA DK 25.11
  • System integration: Component of the UTL 25 digital Inline ULTRA-TURRAX system
  • Compatible stands (examples): Can be mounted on sturdy stands such as the R 6547 H floor stand
  • Material: Robust, heavy-duty and chemical-resistant construction
  • Health and safety benefit: Intended to reduce the risk of hose lines being torn off by securing the chamber
  • Machine protection benefit: Intended to reduce imbalance and protect the mechanical seals of the dispersing tools
  • Ergonomics: Easy to lock in place and remove for regular cleaning cycles

Scope of delivery

  • 1 x IKA AD 25 Mounting support (mounting bracket)

(Important note: The essential DK 25.11 flow-through chamber, the stand, the dispersion drive and the dispersion tools are available separately and are expressly not included in this scope of delivery.)

Individual requirements & accessories

The AD 25 Mounting support is a mechanical component for your in-line system. To set up the system fully and have it ready for operation, you must have the DK 25.11 flow-through chamber, a sturdy floor-standing or telescopic stand (such as the R 6547 H) and the appropriate in-line dispersing tools (e.g. S 25 KV - 25 G - IL). If you wish to process highly viscous, thick liquids using the inline process, we also recommend integrating an upstream pump, as the system itself is not self-priming. Our procurement service will be happy to advise you on the design and configuration of your complete continuous UTL 25 inline system.
