IKA EUROSTAR 60 digital overhead stirrer with LCD display, up to 60 litres, 0020105156

The IKA R 1330 anchor stirrer (MPN 0002022300) is a stirring element made of stainless steel 1.4571 for overhead stirrers. It has a stirrer diameter of 45 mm and a shaft with a diameter of 8 mm and a length of 350 mm. It is intended for medium to highly viscous media that are stirred at low speeds, up to a maximum of 1,000 rpm.A polymer batch that sits thick in the vessel, or a mixture with a high mineral content that is to stay evenly distributed: the R 1330 is intended for tasks like these.Tangential flow of the anchor stirrer with a high shear rate at the edgeThe anchor stirrer moves the medium tangentially, that is, in the circumferential direction around the stirrer axis, and not axially like a propeller stirrer. The shear rate is high at the edge of the stirrer, and few deposits are left on the vessel wall. With viscous batches this matters, because material on the wall is withdrawn from the mixing process.It is used at low speeds. The stirrer diameter of 45 mm determines the minimum width of the opening of the stirring vessel.Typical applicationsHomogenising medium to highly viscous liquids in the laboratoryStirring in polymer reactionsEvenly distributing high mineral content in liquidsBatches where little material should be deposited on the vessel wallWorking at low speeds on an overhead stirrerSuitable for IKA overhead stirrers with an 8 mm chuckThe shaft with a diameter of 8 mm fits into chucks for an 8 mm shaft. These include the IKA overhead stirrers EUROSTAR 20, 40, 60, 100, 200 and 400 (digital and control), RW 20 digital as well as MINISTAR, MICROSTAR and NANOSTAR. In our range you will find EUROSTAR 20, 40, 60, 100, 200 and 400 digital, RW 20 digital, MINISTAR 20, 40 and 80 digital, MICROSTAR 7.5 digital and NANOSTAR 7.5 digital.Whether a stirrer drives the anchor stirrer safely in your medium depends on the viscosity and on the torque of the stirrer. The more viscous the batch, the more torque is required. Therefore check before purchase whether your device is sufficient for your batch and whether the chuck accepts a shaft of 8 mm.MaterialThe wetted parts of the R 1330 are made of stainless steel 1.4571. The weight of the stirrer is 0.151 kg.Technical detailsTypeAnchor stirrerStirrer diameter45 mmShaft diameter8 mmShaft length350 mmMaximum speed1,000 rpmFlowtangentialSuitable formedium to highly viscous mediaMaterial, wetted partsStainless steel 1.4571Weight0.151 kgMountChuck for 8 mm shaftScope of delivery1 x IKA R 1330 anchor stirrer (MPN 0002022300). The overhead stirrer is not included in the scope of delivery.Individual requirements and procurement serviceIf your medium requires a different flow pattern, we carry the IKA R 1342 propeller stirrer for the RW 20 digital, for low to medium viscosity liquids. A stirrer shaft protector, for example the IKA R 401, also fits the overhead stirrer setup. Our procurement service helps with the choice of the suitable stirring element and the overhead stirrer for your batch.

The IKA R 401 stirring shaft guard with hinge (MPN 0020122349) is an essential mechanical safety component for the safe and accident-free operation of overhead stirrers in the laboratory. During intensive mixing and homogenisation of viscous media, high kinetic forces act on the rotating stirring shafts. This professional shaft guard reliably protects laboratory staff from accidental contact with the rotating parts, effectively preventing clothing, hair or gloves from being drawn in. The guard is therefore a fundamental element in risk assessments and compliance with strict health and safety and accident prevention regulations (UVV). Ergonomic access thanks to an integrated hinge mechanism The design highlight of the R 401 model is its integrated, smooth-running hinge system. Unlike rigid protective covers, this hinged system architecture allows quick, unobstructed access to the drill chuck and the stirrer tool in use. Laboratory staff can carry out tool changes, adjustments to the immersion depth or cleaning tasks in a way that protects the material, without the need for time-consuming dismantling of the entire guard. This ensures a smooth workflow with high time efficiency in daily multi-user operation. Material stability and unrestricted process visibility The protective screen is made from a highly transparent, impact-resistant and specialised plastic material. This choice of material guarantees uncompromising chemical resistance to transient splashes of acids, alkalis or organic solvents. The material’s excellent optical clarity ensures that visual monitoring of the stirring process, transient flow patterns or any delays in boiling within the sample vessel remains completely unrestricted and error-free at all times. Technical details Design & Material Product group: Laboratory accessories / Health and safety (Accessory) Protection principle: Mechanical barrier against rotating components Special feature: Integrated hinged flap for quick access to tools Protective screen material: Highly transparent, impact-resistant and chemical-resistant plastic Visibility: Unrestricted visual monitoring of the material being stirred Compatibility & Installation System compatibility: Universally compatible with IKA EUROSTAR basic and control overhead stirrers Mounting method: Stable, vibration-free mounting directly onto the stand frame or the equipment mount Height adjustability: Flexibly adaptable to the respective vessel geometry and shaft length Contents of delivery 1 x IKA R 401 stirrer shaft guard with hinge (MPN: 0020122349) 1 x Complete set of fitting materials, including fasteners 1 x Quick guide / Safety guide for accident prevention Individual requirements & accessories To ensure a fully compliant and safe mixing workstation, we stock the complete range of original IKA system peripherals: Overhead stirrers: Optimised for the high-performance powerhouses of the IKA EUROSTAR 20, 40, 60, 100 or 200 series (both basic and control models). Stands & Sockets: Extremely stable IKA telescopic stands (e.g. R 2723 or R 2722) and robust cross-sockets (e.g. R 270) for vibration-free securing of the entire experimental setup. Stirring tools: A wide-ranging B2B range of PTFE-coated and stainless steel stirring elements, such as propeller stirrers, anchor stirrers, paddle stirrers and dissolver discs. Make use of our technical procurement service to ensure the reliable design of your laboratory set-ups.
