IKA KS 3000 i control Incubating Shaker, 10 to 500 rpm, up to 80 °C, 50-litre Chamber, 0003940000
€5,009.25
% Manufacturer's RRP: €6,679.00 25% below manufacturer's RRP
- Incubation shaker for unattended operation in a temperature-controlled environment
- Heating temperature: room temperature +5 to 80 °C, setting accuracy 0.1 K
- Speed 10 to 500 rpm in 1-rpm increments, shaking stroke 20 mm, up to 7.5 kg
- Internal chamber 330 x 330 x 258 mm (50 l), PMMA lid, automatic stop when lid is open
- Interfaces: RS 232 and USB-B, controlled via labworldsoft
- PT 1000.80 temperature sensor and USB-A-B cable included in the scope of delivery
- 3-year manufacturer’s warranty upon registration within 90 days
Product information "IKA KS 3000 i control Incubating Shaker, 10 to 500 rpm, up to 80 °C, 50-litre Chamber, 0003940000"
Shaking temperature-controlled samples for hours whilst leaving the unit to run unattended: that is what the IKA KS 3000 i control is designed for. According to IKA, the incubation shaker is designed for unattended operation in a temperature-controlled environment. It shakes in a circular motion with a 20 mm stroke at 10 to 500 rpm, heats from room temperature plus 5 K to 80 °C and can hold up to 7.5 kg. The inner chamber has a capacity of 50 l.
Temperature under control
A PID control system with two PT-1000 sensors maintains the setpoint temperature, which is adjustable in increments of 0.1 K. With a sensor in the vessel, the control accuracy is ±0.5 K (1 vessel containing 0.5 l of water, room temperature 22 °C, 37 °C). Temperature stability is ±0.05 K (1 vessel containing 0.5 l, room temperature 25 °C, 37 °C), whilst homogeneity across five vessels, each containing 0.5 l, is ±0.5 K. There is a connection socket for an additional sensor in the working chamber. The sensor supplied is the PT 1000.80, made of stainless steel. The heating power is 1000 W.
Hood, bath and safety features
The lid is made of PMMA; the shaker stops automatically when the lid is opened and switches itself off in the event of a fault. The controls have an antimicrobial coating to reduce bacteria. A drip tray with a drain hose at the rear collects any liquid. Speed and time are shown on a large LED display; the timer ranges from one second to 999 hours, or alternatively, the unit can run continuously.
Typical applications
- Shaking temperature-controlled samples for several hours without supervision
- Incubation at a constant temperature, for example at 37 °C
- Documented runs via RS 232, USB-B and the labworldsoft software
- Shaking of vessels of various sizes using retaining clamps or a universal attachment
- Samples requiring a shaking load of up to 7.5 kg, including the attachment
KS 3000 i control or larger alternatives
The KS 4000 i control offers more space and load capacity, with a chamber measuring 440 x 440 x 352 mm and a shaking load of 20 kg. Those who only wish to shake and not control the temperature can opt for the KS 260 basic, which operates at room temperature. Like the KS 3000 i control, the KS 260 control NOL has a shaking capacity of 7.5 kg.
| Model | Speed | Shaking stroke | Shaking load | Heating | Weight |
| KS 3000 i control (this unit) | 10 to 500 rpm | 20 mm | 7.5 kg | 1000 W, up to 80 °C | 35 kg |
| KS 4000 i control | 10 to 500 rpm | 20 mm | 20 kg | 1000 W, up to 80 °C | 50 kg |
| KS 260 basic | 0 to 500 rpm | 10 mm | 7.5 kg | no | 8.5 kg |
Technical details
| Type of movement | circular |
| Shaking stroke | 20 mm |
| Permissible shaking weight (including attachment) | 7.5 kg |
| Motor power input / output | 45 W / 10 W |
| Permissible duty cycle | 100 % |
| Speed range | 10 to 500 rpm, in 1 rpm steps, deviation 1 % |
| Timer | Yes, 7-segment LED, 1 s to 59,940 min |
| Operating mode | Timer and continuous operation |
| Heating temperature range | Room temperature +5 to 80 °C |
| heating power | 1000 W |
| Setting accuracy for setpoint temperature | 0.1 K |
| Control accuracy with sensor (1 vessel, 0.5 l H2O, 22 °C, 37 °C) | ±0.5 K |
| Temperature stability (1 vessel, 0.5 l, 25 °C, 37 °C) | ±0.05 K |
| Temperature homogeneity (5 vessels, 0.5 l, 25 °C, 37 °C) | ±0.5 K |
| Inner chamber working area (W x H x D) | 330 x 330 x 258 mm |
| Internal chamber volume | 50 l |
| Materials | Housing: powder-coated sheet steel, cover: PMMA, front film: polyester, front panel: painted ABS |
| Dimensions (W x H x D) | 465 x 430 x 695 mm, height with lid open 875 mm |
| Weight | 35 kg |
| Permissible ambient temperature range | 15 to 32 °C |
| Permissible relative humidity | 80 % |
| Protection class | IP 30 (DIN EN 60529) |
| Interfaces | RS 232, USB-B |
| Mains connection | 230 V, 50/60 Hz, power consumption 1120 W |
Scope of delivery
- 1 x IKA KS 3000 i control incubation shaker
- 1 x PT 1000.80 temperature probe, stainless steel
- 4 x clamping screws, short
- 1 x USB A-to-B cable
Lids are not included in the Scope of delivery and must be ordered separately to fit the vessels.
Warranty and disposal
IKA manufacturer’s warranty: 2 years; extended to 3 years upon registration at ika.com/register within 90 days of purchase. Attachments and accessories are excluded. As an electrical appliance, the KS 3000 i control must be disposed of via the separate collection scheme for waste electrical equipment after use.
Individual requirements and procurement service
The following items are compatible with the unit: the universal attachment AS 260.1, the clamp holder AS 260.2 with clamps ranging from 10 to 2000 ml, the dish attachment AS 260.3, the separating funnel attachment AS 260.5, the base holder AS 1.60 with clamping roller AS 1.61, the STICKMAX and an adjustable tube rack. Also included are the PC 1.1 cable, labworldsoft in three versions, as well as factory calibration certificates and IQ/OQ documentation. Our procurement service will assist you in selecting the right attachments for your vessels.
Frequently asked questions
How big is the interior? The inner chamber measures 330 x 330 x 258 mm and has a volume of 50 l.
What temperatures are possible? From room temperature plus 5 K to 80 °C, adjustable in increments of 0.1 K.
Is a temperature probe included? Yes, a stainless steel PT 1000.80 is included in the Scope of delivery.
How long is the warranty valid for? IKA manufacturer’s warranty: 2 years, extended to 3 years upon registration at ika.com/register within 90 days of purchase.
