IKA S 10 N - 10 G - ST Dispersing Tool, Ø 10 mm, for T 10, 0004446700
€1,265.25
% Manufacturer's RRP: €1,687.00 25% below manufacturer's RRP
- Stator 10 mm, rotor 7.5 mm, air gap 0.25 mm
- Operating range 1 to 100 ml, immersion depth 23 to 100 mm
- ST version for the homogenisation of fibrous samples
- Permitted up to 30,000 rpm, maximum circumferential speed 11.8 m/s
- PTFE and AISI 316L, suitable for solvents and abrasive substances
- Up to 180 °C for short periods, sterilisable using all methods
Product information "IKA S 10 N - 10 G - ST Dispersing Tool, Ø 10 mm, for T 10, 0004446700"
The working range of the S 10 N - 10 G - ST (0004446700) extends up to 100 ml. The tool has a 10 mm stator and a 7.5 mm rotor and is designed for use with the T-10 series drives. The shaft runs in a PTFE split-ring bearing.
ST for fibrous samples
IKA uses ST tools for the homogenisation of fibrous samples. The immersion depth is 23 to 100 mm, the installation length is 115 mm, and the weight is 0.075 kg.
Gap and speed
The gap between the rotor and stator is 0.25 mm. A maximum speed of 30,000 rpm is permitted, resulting in speeds of up to 11.8 m/s at the rotor circumference. The final particle size is 5 to 25 µm for suspensions and 1 to 10 µm for emulsions.
Material and temperature
The parts in contact with the product are made of PTFE and AISI 316L. The tool is suitable for solvents and abrasive substances; the pH range is from 2 to 13. The short-term operating temperature is up to 180 °C, and sterilisation may be carried out using any method.
Typical applications
- Disintegration of fibrous samples in volumes of 1 to 100 ml
- Emulsifying and suspending small batches
- Working with solvents in the pH range 2 to 13
- Samples containing abrasive components
- Processes involving short-term temperatures of up to 180 °C
Technical details
| Processable volume (H2O) | 0.001 to 0.1 l |
| Stator diameter | 10 mm |
| Rotor diameter | 7.5 mm |
| Stator/rotor gap width | 0.25 mm |
| Max. permissible speed | 30,000 rpm |
| Maximum circumferential speed | 11.8 m/s |
| Penetration depth | 23 to 100 mm |
| Installation length | 115 mm |
| Bearing | PTFE split ring bearing |
| Materials in contact with the product | PTFE, AISI 316L |
| pH range | 2 to 13 |
| Suitable for solvents | Yes |
| Suitable for abrasive substances | Yes |
| Max. operating temperature | 180 °C (for short periods) |
| Sterilisability | all methods |
| Final particle size of suspensions | 5 to 25 µm |
| Final particle size (emulsions) | 1 to 10 µm |
| Weight | 0.075 kg |
Scope of delivery
- 1 x IKA S 10 N - 10 G - ST dispersing tool (single tool)
- The drive (T 10 basic or T 10 battery) is not included in the Scope of delivery.
Smaller stator or different drive
The S 10 N - 8 G ST is available for 1 to 50 ml and an 8 mm stator, also with 30,000 rpm and the same final fineness grades. The S 25 N - 10 G has the same stator and rotor dimensions as shown here (10 and 7.5 mm); it is designed for T-25 drives, runs at up to 25,000 rpm and reaches 9.8 m/s. Compared with the S 10 N - 8 G ST, the working volume here is up to 100 ml instead of 50 ml. The rotor is larger at 7.5 mm instead of 6.1 mm; at the same speed, the circumferential speed is therefore 11.8 m/s instead of 9.6 m/s.
Individual requirements and procurement service
LT Laborhandel can source the appropriate T-10 drive and other accessories on request. The procurement service will assist you in selecting the right equipment for your sample volume.
