IKA S 25 N - 25 G - ST Dispersing Tool, Ø 25 mm, for T 25, 0004447500
€1,407.00
% Manufacturer's RRP: €1,876.00 25% below manufacturer's RRP
- ST tool for fibrous samples, stator 25 mm, rotor 20 mm
- Working range 0.05 to 2 l, immersion depth 40 to 165 mm
- Permissible up to 25,000 rpm, maximum circumferential speed 26.2 m/s
- Final particle size 15 to 50 µm (suspensions), 1 to 10 µm (emulsions)
- PTFE slotted ring bearing, PTFE and AISI 316L, suitable for use with solvents
- Up to 180 °C for short periods; can be sterilised using all methods
Product information "IKA S 25 N - 25 G - ST Dispersing Tool, Ø 25 mm, for T 25, 0004447500"
The S 25 N - 25 G - ST (0004447500) is an ST model. According to IKA, ST tools are used for the comminution of fibrous samples. The tool, with a 25 mm stator diameter, processes sample volumes from 50 to 2,000 ml and is compatible with the T 25 digital and T 25 easy clean digital or control drives.
Geometry and speed
The rotor and stator have diameters of 20 and 25 mm, respectively, with a gap of 0.5 mm between them. At the maximum permissible speed of 25,000 rpm, this results in a maximum circumferential speed of 26.2 m/s. The final fineness ranges from 15 to 50 µm for suspensions and from 1 to 10 µm for emulsions. The installation length is 194 mm, and the immersion depth ranges from 40 to 165 mm.
Bearing and Material
The shaft is mounted in a PTFE split-ring bearing. PTFE and AISI 316L come into contact with the medium. The tool is suitable for solvents and abrasive substances and operates within a pH range of 2 to 13. Operating temperatures of up to 180 °C are permissible for short periods; it can be sterilised using all methods.
Choice within the S-25 range
The same stator size is also available with a ball bearing, PTFE seal and FFKM O-ring as the S 25 KD - 25 G ST, which additionally permits a vacuum down to 100 mbar and is designed for temperatures up to 150 °C. For vacuum down to 1 mbar and pressure up to 6 bar, the S 25 KV, 25 G is suitable. Smaller volumes of up to 50 ml are handled by the S 10 N, 8 G ST on the T 10.
Typical applications
- Grinding of fibrous samples in volumes ranging from 50 to 2,000 ml
- Dispersing and emulsifying on a laboratory scale up to 2 l
- Working with solvents and abrasive solids
- Processing of the instrument by sterilisation using all methods
Technical details
| Working range (H2O) | 0.05 to 2 l |
| Stator diameter | 25 mm |
| Rotor diameter | 20 mm |
| Stator/rotor air gap | 0.5 mm |
| Maximum permissible speed | 25,000 rpm |
| Maximum circumferential speed | 26.2 m/s |
| Penetration depth | 40 to 165 mm |
| Installation length | 194 mm |
| Bearing and seal | Shaft in PTFE split-ring bearing |
| Materials in contact with the product | PTFE, AISI 316L |
| pH range | 2 to 13 |
| Suitable for solvents | Yes |
| Suitable for abrasive substances | Yes |
| Max. operating temperature | 180 °C |
| Sterilisability | all methods |
| Final particle size of suspensions | 15 to 50 µm |
| Final particle size (emulsions) | 1 to 10 µm |
| Weight | 0.4138 kg |
Scope of delivery
- 1 x IKA S 25 N - 25 G - ST dispersing tool (single tool)
The drive is not included in the Scope of delivery. For complete set-ups, IKA offers the T 25 digital Solution.
Individual requirements and procurement service
If you require the tool to be supplied together with the appropriate drive unit, do you need a second tool for changing, or guidance on selecting the correct geometry? LT Laborhandel will put together the right combination for your application via its procurement service.
