Memmert UN260plus Universal Oven, 256 litres, TwinDISPLAY, natural convection, 300 °C

Large capacity for sensitive samples: Memmert UN260plus

The Memmert UN260plus universal cabinet is the ideal large-capacity unit for laboratories, research institutions and industry where plenty of space is required but an air flow would be undesirable. With an internal volume of 256 litres and natural convection (fanless), this cabinet guarantees absolutely turbulence-free heat transfer. It is the perfect choice for the gentle drying, ageing or temperature control of fine powders, light granulates, paper or sensitive biological samples that must not be stirred up.

TwinDISPLAY: Maximum control for complex processes

Despite the gentle, fanless heating, the ‘Plus’ model offers full programmability. The TwinDISPLAY, with its two high-resolution TFT touchscreens, makes creating sophisticated temperature ramps and process cycles child’s play. The electronically controlled exhaust air flap regulates the fresh air supply precisely in 10% increments. A major advantage with this large chamber volume is the HeatBALANCE function: this allows the heating power to be adjusted specifically between the upper and lower sections of the chamber to compensate for asymmetrical loads or differing thermal masses.

Redundant safety and comprehensive documentation

Two independently operating Pt100 sensors (DIN Class A) ensure maximum process reliability. If one sensor fails, the second seamlessly takes over temperature control. The integrated AutoSAFETY system reliably protects your valuable samples through visual and audible alarms, as well as automatic heating shutdown in the event of deviations. All process data is stored in the internal data logger and can be read out via USB or Ethernet using the supplied AtmoCONTROL software, which is FDA-compliant (GMP/GLP).

Detailed technical specifications:

• Model: UN260plus (natural convection / fanless)
• Volume: 256 litres
• Temperature range: Min. 5 °C above room temperature up to +300 °C
• Control system: TwinDISPLAY (2x TFT touchscreens, fully programmable)
• Internal dimensions (W x D x H): 640 x 500 x 800 mm
• External dimensions (W x D x H): 824 x 684 x 1183 mm (depth plus 56 mm door handle)
• Electrical connection: 230 V, 50/60 Hz
• Power consumption: approx. 3400 W (Please ensure there is adequate circuit protection at the installation site!)
• Max. load: 300 kg (unit as a whole) / 20 kg (per drawer)

Contents of delivery:

• 1x Memmert UN260plus universal cabinet
• 2x stainless steel grates (electropolished)
• 1x factory calibration certificate (at +160 °C)
• 1x USB stick (including AtmoCONTROL software)
• Operating instructions

Accessories & Service:

Do you require additional, reinforced grids (for heavier samples) or a special calibration? Please make use of our bespoke procurement service if you cannot find the accessories you require directly in the shop.
