IKA T 18 digital Solution Disperser Set, including tool and stand, 0009024700

For those who want to get started straight away, without having to assemble the drive, tool and stand individually first, the IKA T 18 digital Solution (0009024700) offers a fully coordinated complete package. The set combines the tried-and-tested T 18 digital drive with the standard S 18 N - 19 G dispersing tool and a sturdy plate stand complete with boss head, all ready for use straight out of the box.

Everything included for an immediate start

Instead of ordering four separate items and checking whether they fit together, the Solution version supplies all components in a single package:

• Drive: IKA T 18 digital ULTRA-TURRAX with 500-watt power consumption
• Dispersing tool: S 18 N - 19 G with PTFE bearings for coarse to medium-duty applications
• Mounting: R 1826 plate stand including R 182 boss head for a stable, low-vibration base

Digital speed control with LED display

The speed range extends from 3,000 to 25,000 revolutions per minute, is infinitely variable and has a deviation of around 1 % according to the data sheet. The LED display shows the set value directly, so that once process parameters have been determined, they can be noted down and repeated for subsequent trials. With an output power of 300 watts, the drive can process samples with a viscosity of up to 5,000 mPas. With a permissible duty cycle of 100 %, the drive can also be operated continuously for longer process stages without the need to schedule a cooling break between batches.

Tool S 18 N - 19 G ready for use

The supplied tool covers a working range of 10 to 1,500 millilitres and, with its coarsely toothed geometry, is suitable for the pre-shredding of solid components as well as for more viscous media. The rotor shaft is mounted in PTFE, which is resistant to most solvents, acids and alkalis. Details on the design and limit values of the tool can be found in the separately listed S 18 N - 19 G dispersing tool.

Interchangeable tool for different samples

Even though the set is already equipped with a suitable tool, the drive remains compatible with the entire S-18 tool range. A quick-release coupling allows for tool changes without the need for a tool kit, meaning that, if required, a finer tool for smaller end products or a single-use tool for contamination-sensitive batches can be fitted. For day-to-day use with varying sample types, this is a noticeable advantage over a permanently fitted tool: the set covers the basics but grows in line with the laboratory’s requirements.

Typical areas of application

As a complete package, the T 18 digital Solution is particularly suitable for new purchases and the setting up of additional workstations:

• Re-equipping laboratory workstations without existing dispersion accessories
• Preparation of emulsions and suspensions in sample preparation
• Homogenisation of samples in quality control and routine analysis
• Teaching and training laboratories where a ready-to-use kit is required

Brief overview within the T-18 range

In addition to this set, we offer the T 18 digital ULTRA-TURRAX drive (without tool) for those who already own their own accessories, as well as the more compact T 18 mini digital Solution with a brushless drive and lower motor power for smaller work surfaces. Anyone wishing to reorder just the included tool separately can find it as the S 18 N - 19 G dispersing tool.

Technical details

Scope of delivery

• 1 x IKA T 18 digital ULTRA-TURRAX (drive unit)
• 1 x S 18 N - 19 G dispersing tool
• 1 x R 1826 plate stand
• 1 x R 182 boss head

Differences from the neighbouring series

If you are also looking for a brushless motor with a timer, the IKA T 18 brushless series offers a comparable set with an additional timer function in the form of the T 18 brushless digital Solution. An overview of all dispersers available from us can be found in the ‘Dispersers’ category.

Application, installation and maintenance

The supplied plate stand ensures a secure, low-vibration base even at high speeds and is particularly suitable for longer or unattended process stages. Operation is permitted at an ambient temperature of 5 to 40 °C and a relative humidity of up to 80 % at 31 °C, decreasing linearly to a maximum of 50 % at 40 °C. The PTFE bearing of the supplied tool must not run dry; the medium serves both as lubrication and cooling. After use, the tool can be disconnected from the drive for cleaning or sterilisation, as can the stand, which can be detached again for the next configuration. At the end of its service life, the drive, as an electrical appliance, does not belong in household waste but in the separate collection for waste electrical and electronic equipment.

When the complete set is worthwhile

For laboratories that do not yet own a T-18 drive, the set saves time on ordering and compatibility checks compared to purchasing the drive, tool and stand separately. On the other hand, those who already have a suitable stand or several tools and only require an additional drive may find it more cost-effective to opt for the separately available T 18 digital ULTRA-TURRAX without the set. For a second or third workstation with identical equipment, however, the complete set is once again a suitable option, as each station is equipped independently of the others.

Individual requirements & procurement service

For regulated environments where the introduction of equipment must be documented, we also arrange qualification documents for the T 18 digital Solution, such as IQ/OQ documents, factory calibration certificates or general certificates according to 2.2/3.1. Do you also require additional or alternative tools for abrasive or particularly viscous media, a second stand for an extra workstation, or assistance in selecting the right configuration? Through our procurement service, we support you with procurement and documentation.

Frequently asked questions

Is the T 18 digital Solution ready for immediate use?
Yes, the drive, the S 18 N - 19 G dispersing tool and the plate stand are included in the set and are designed to work together.

Which tool is included in the set?
The S 18 N - 19 G with PTFE bearings, suitable for coarse pre-shredding and a working volume of 10 to 1,500 millilitres.

How does the set differ from the T 18 digital drive sold separately?
The T 18 digital ULTRA-TURRAX drive, available separately, is supplied without the tool or stand; the Solution Set already includes both components.

Can I use a different tool instead of the one supplied?
Yes, the drive is compatible with the entire S-18 range of tools, so finer or coarser variants can be retrofitted if required.

Is the stand permanently attached to the drive?
No, the drive, tool and stand can be detached from one another, for example for cleaning or for use at different workstations.

Are qualification documents available for the set?
Yes, we can arrange IQ/OQ documents, factory calibration certificates and general certificates according to 2.2/3.1 for the T 18 digital Solution on request.
