IKA HS 25 EC - DW Holder, washing machine mount for dispersing tools, 0025007380

IKA cites dispersing applications in biochemistry and pharmaceuticals as typical uses for the S 25 EC - T - C - 25 G - ST (0025002595), such as the emulsification of heat-sensitive pharmaceutical intermediates. The autoclavable tool has a 25 mm stator and a 20 mm rotor, processes volumes of 0.05 to 2 l and incorporates a temperature sensor.Temperature and operating hoursThe integrated sensor measures from 0 to 125 °C and displays the value during operation. The drive keeps track of operating hours; a message appears on the display when maintenance is due. IKA specifies the T 25 easy clean control as the drive. The maximum operating temperature of the unit is 120 °C.Cleaning according to the ‘easy-clean’ principleWhen the clamp is turned and lowered, the shaft and rotor drop out until the rotor has completely left the stator. The shaft tube can then also be rinsed internally. The shaft runs in a ceramic plain bearing; the parts in contact with the product are made of AISI 316L and ceramic.Gap, fineness and dimensionsThe gap is 0.5 mm; at 25,000 rpm, a speed of 26.2 m/s is achieved at the rotor circumference. The final fineness ranges from 15 to 50 µm for suspensions and from 1 to 10 µm for emulsions. The tool has a plunge depth of 45 to 150 mm, is 191 mm long, weighs 0.634 kg and is suitable for solvents and abrasive materials.Typical applicationsDispersion in biochemistry and pharmaceuticals, including heat-sensitive intermediatesBatches of 0.05 to 2 l with temperature measurementEmulsions with final particle sizes of 1 to 10 µmSamples containing abrasive componentsWork involving solventsSample series with maintenance instructions based on operating hoursTechnical detailsProcessable volume (H2O)0.05 to 2 lStator diameter25 mmRotor diameter20 mmStator/rotor gap width0.5 mmMax. permissible speed25,000 rpmMaximum circumferential speed26.2 m/sPenetration depth45 to 150 mmInstallation length191 mmBearing typeCeramic plain bearingMaterials in contact with the productAISI 316L, ceramicpH range2 to 13Suitable for solventsYesSuitable for abrasive substancesYesTemperature measurement range0 to 125 °CMax. operating temperature120 °CSterilisabilityall methods except hot airFinal particle size of suspensions15 to 50 µmFinal particle size of emulsions1 to 10 µmWeight0.634 kgScope of delivery1 x IKA S 25 EC - T - C - 25 G - ST dispersing tool (single tool)The T 25 easy clean control drive is not included in the Scope of delivery.With and without a sensorThe S 25 EC - C - 25 G - ST has the same geometry but without a temperature sensor; its operating temperature is 180 °C and it has an immersion depth of 35 to 150 mm. The S 25 EC - T - C - 25 G operates with a sensor, but features a 17 mm rotor and a speed of 22.2 m/s. Those requiring an 18 mm rotor and particle sizes of 1 to 5 µm for emulsions will find this in the S 25 EC - T - C - 25 F.Individual requirements and procurement serviceWe can supply the T 25 easy clean control drive and other tools on request. The procurement service assists with selection.

Dispersing meat or vegetables in liquid: IKA recommends the S 25 EC - C - 25 G - ST (0025002590) for this purpose in food analysis. This easy-clean unit has a 25 mm stator diameter, a 20 mm rotor and processes volumes from 0.05 to 2 l.Removing the shaft and rotorAfter turning and lowering the clamp, the shaft and rotor fall out. The shaft tube can then be rinsed from the inside. The immersion depth is 35 to 150 mm, and the installation length is 191 mm.Performance dataA maximum speed of 25,000 rpm is permitted, resulting in speeds of up to 26.2 m/s at the rotor circumference. The gap between the rotor and stator is 0.5 mm. The final particle size is 15 to 50 µm for suspensions and 1 to 10 µm for emulsions. The tool weighs 0.4 kg.Bearings and materialsThe shaft runs in a ceramic plain bearing; the parts in contact with the product are made of AISI 316L and ceramic. The tool is suitable for solvents and abrasive substances. The pH range is from 2 to 13, and the operating temperature is up to 180 °C. It may be sterilised using any method.DrivesIKA approves this tool exclusively for use with the T 25 easy clean digital and the T 25 easy clean control. The T 25 easy clean digital Solution Set is also listed.Comparison within the 25 mm seriesThe S 25 EC - C - 25 G operates with a 17 mm rotor diameter and a speed of 22.2 m/s. The S 25 KD - 25 G ST has the same rotor and gap dimensions, uses ball bearings and allows for a vacuum of up to 100 mbar. The S 25 EC - T - C - 25 G is available with a temperature sensor and a 17 mm rotor.Typical applicationsDispersion in food analysis, for example meat or vegetables in liquidBatch sizes from 0.05 to 2 lWork with solventsSamples containing abrasive particlesSample change with internal cleaning of the shaft tubeTechnical detailsWorking range (H2O)0.05 to 2 lRecommended operating range50 to 2,000 mlStator diameter25 mmRotor diameter20 mmStator/rotor gap width0.5 mmMaximum permissible speed25,000 rpmMaximum circumferential speed26.2 m/sPenetration depth35 to 150 mmInstallation length191 mmBearingCeramic plain bearingsMaterials in contact with the productAISI 316L, ceramicpH range2 to 13Suitable for solventsYesSuitable for abrasive substancesYesMax. operating temperature180 °CSterilisabilityall methodsFinal particle size of suspensions15 to 50 µmFinal particle size (emulsions)1 to 10 µmWeight0.4 kgScope of delivery1 x IKA S 25 EC - C - 25 G - ST dispersing tool (single tool)The drive is not included in the scope of delivery.Individual requirements and procurement serviceDrive unit, replacement tool or selection guide for your application: we are happy to assist on request. The procurement service is the direct way to do this.

The T 25 easy clean control ULTRA-TURRAX uses an RFID-enabled tool to measure the sample temperature, thereby protecting heat-sensitive formulations from overheating. A dispersing tool is not supplied with the drive unit; it is selected from the relevant tool range to suit the temperature measurement function.Temperature measurement and tool recognition via RFIDUsing a tool fitted with a temperature sensor, the unit measures the sample temperature within a range of 0 to 125 degrees Celsius, with a resolution of 0.1 Kelvin and an accuracy of ±1 Kelvin. Continuous temperature monitoring with an adjustable limit protects against overheating, whilst the tool simultaneously records its operating hours via RFID, which simplifies maintenance planning. In addition to the standard tool, the range of accessories includes further variants with temperature sensors in diameters of 18 and 25 millimetres, as well as a flat version.Easy-clean maintenance without dismantlingAs with the digital version, the tool on the control model can be opened for cleaning without dismantling the entire rotor-stator unit. The brushless DC motor runs at 70 dB(A) without a tool fitted, making it comparatively quiet and free from carbon dust. All dispersing tools in the S-25 series are compatible with this drive unit; even classic tools without temperature sensors can be used with it for tasks where temperature measurement is not a factor.Operation, remote control and connectionThe speed is continuously adjustable between 3,000 and 25,000 revolutions per minute via an LED display, whilst a timer manages recurring process times. In addition to operation via the unit itself, the T 25 easy clean control can be controlled using the optional WiCo remote control, which is not included in the scope of delivery. A micro-USB interface connects the unit to labworldsoft; it operates on a mains supply of 220 to 240 volts, or 100 to 120 volts on request for locations outside Europe. The housing is protected to IP 30 in accordance with DIN EN 60529 and is designed for a 100 per cent duty cycle at a permissible ambient temperature of 5 to 40 degrees Celsius.Documentation and ConformityAs with the digital version, a separate EU Declaration of Conformity is available for download for this drive unit, along with a dedicated data sheet. The operating instructions are shared with the digital version and are available in 14 languages.Typical applicationsThe temperature monitoring feature makes the unit particularly suitable for applications where samples may be damaged by excessive heating.Dispersion of heat-sensitive pharmaceutical and cosmetic formulationsProcesses requiring documented maintenance via RFID operating hours recordingHomogenisation where a fixed temperature limit must be maintainedRemote control via WiCo for applications in fume cupboardsSelection guide: control, digital or Set?If temperature measurement is not required, the more affordable T 25 easy clean digital ULTRA-TURRAX is usually sufficient. Those who do not yet own a temperature-measuring tool will find the T 25 easy clean control Solution to be the ideal complete set, comprising the tool, stand and cross-joint. For more compact, networked applications with Wi-Fi and Ethernet, the standalone T 25 mini control Solution is available; it covers smaller volumes at lower power. For higher volumes with a more powerful drive, but without temperature measurement, the T 25 digital ULTRA-TURRAX is suitable.Technical detailsThe following table summarises the key specifications for the drive, temperature measurement and connections, as specified by IKA for the ‘control’ variant of the T 25 easy clean series.Motor power input / output500 W / 400 WProcessable volume (H₂O)1 to 2,000 mlMax. viscosity5,000 mPasSpeed range3,000 to 25,000 rpm, continuously variable (2% deviation)Speed displayLEDMotor typebrushless, direct currentNoise level without tools70 dB(A)Boom diameter / boom length13 mm / 160 mmTimerYes, LED displayPermissible duty cycle100 %Permissible ambient temperature / humidity5 to 40 °C / 80 %Protection classIP 30 in accordance with DIN EN 60529USB interfaceMicro-USBPower rating220 to 240 V, 50/60 Hz, 500 W (alternative voltage option: 100 to 120 V)Temperature measurement range0 to 125 °CTemperature measurement resolution0.1 KTemperature measurement accuracy±1 KDimensions (W x H x D)89 x 270 x 161 mmWeight3 kgContentsT 25 easy clean control ULTRA-TURRAX drive unitUSB cable, USB A to Micro-B, 2 mA dispersing tool and the WiCo remote control are not included in the scope of delivery and must be ordered separately if required.Regulatory informationThis device is an electrical appliance within the meaning of the German Electrical and Electronic Equipment Act (ElektroG). The WEEE registration number of the manufacturer, IKA, is DE 66784213. Information on the return of end-of-life equipment can be found on our Environment and Disposal page.Warranty and procurement serviceThe IKA manufacturer’s warranty applies to the T 25 easy clean control ULTRA-TURRAX: 2 years, extended to 3 years upon registration at ika.com/register within 90 days of purchase. For dispersing tools with temperature sensors, stands or the WiCo remote control, our procurement service will handle the assembly.

The S 25 EC - T - C - 25 F (0025007199) measures the temperature within the batch itself: the mould contains a sensor for 0 to 125 °C. It has a 25 mm stator and an 18 mm rotor, processes volumes from 0.01 to 2 l and follows the ‘easy-clean’ principle. IKA specifies the T 25 easy clean control as the drive unit.Sensor and operating hoursTemperature is measured during operation via the integrated sensor. The tool also records operating hours. When maintenance is due, a message appears on the drive’s display. The tool’s maximum operating temperature is 120 °C.easy cleanAfter turning and lowering the clamp, the shaft and rotor fall out. The shaft tube can then be rinsed from the inside. The shaft runs in a ceramic plain bearing; the parts in contact with the product are made of AISI 316L and ceramic.Geometry and precisionThe gap between the rotor and stator is 0.5 mm. A speed of 25,000 rpm is permitted, with speeds of up to 23.6 m/s at the rotor circumference. The immersion depth is 45 to 150 mm, and the installation length is 191 mm. The final fineness is 5 to 25 µm for suspensions and 1 to 5 µm for emulsions. The tool weighs 0.634 kg and is suitable for solvents and abrasive substances. The pH range is from 2 to 13; sterilisation may be carried out using any method except hot air.Without a sensor or with a different rotorWithout a temperature sensor, the same geometry is available as the S 25 EC - C - 25 F with an operating temperature of up to 180 °C. The S 25 EC - T - C - 25 G operates with a sensor, but features a 17 mm rotor and a speed of 22.2 m/s.Typical applicationsDispersing in the cosmetics sectorBatches from 0.01 to 2 l with temperature measurementEmulsions with final particle sizes of 1 to 5 µmWork with solventsBatch runs with maintenance alerts based on operating hoursTechnical detailsWorking range (H2O)0.01 to 2 lRecommended working range100 to 2,000 mlStator diameter25 mmRotor diameter18 mmStator/rotor gap width0.5 mmMax. permissible speed25,000 rpmMaximum circumferential speed23.6 m/sPenetration depth45 to 150 mmInstallation length191 mmBearingCeramic plain bearingsMaterials in contact with the productAISI 316L, ceramicpH range2 to 13Suitable for solventsYesSuitable for abrasive substancesYesTemperature measurement range0 to 125 °CMax. operating temperature120 °CSterilisabilityall methods except hot airOperating hours displayYes, maintenance reminder on the drive displayFinal fineness of suspensions5 to 25 µmFinal fineness of emulsions1 to 5 µmWeight0.634 kgScope of delivery1 x IKA S 25 EC - T - C - 25 F dispersing tool (single tool)The T 25 easy clean control drive is not included in the Scope of delivery.Individual requirements and procurement serviceWe can supply the T 25 easy clean control drive and other tools on request. The procurement service can assist with selection.

The T 25 easy clean digital ULTRA-TURRAX is the drive unit in the IKA T 25 easy clean series, designed for laboratories that need to clean quickly and thoroughly between batches. The tool can be opened for cleaning without having to completely dismantle the rotor-stator unit, which saves time when changing products frequently and prevents cross-contamination. A dispersing tool is not included with the unit; it is selected separately to suit the specific application.The easy-clean principle in practiceTools in the easy-clean series are identified by the abbreviation ‘EC’ in their name and can be opened for cleaning without the need to dismantle the entire drive unit. This saves users the time-consuming process of changing tools and completely dismantling the unit when, for example, they are processing a cosmetic emulsion in the morning and a different formulation in the afternoon. A brushless DC motor drives the tool, which reduces carbon dust in the cleanroom and keeps operation comparatively quiet at 70 dB(A) when no tool is fitted.Display, timer and operationThe speed is shown on an LED display and can be adjusted continuously between 3,000 and 25,000 revolutions per minute with a tolerance of 2 per cent. A built-in timer with its own LED display manages recurring process times, meaning a batch does not need to be stopped manually. A micro-USB interface is provided for connection to labworldsoft, via which parameters can be documented.Performance data and mechanical designWith a power consumption of 500 watts and an output power of 400 watts, the unit processes volumes of 1 to 2,000 millilitres of water and media with a viscosity of up to 5,000 mPas. The arm measures 13 millimetres in diameter and 160 millimetres in length; the housing is protected against dust and coarse foreign particles to IP 30 in accordance with DIN EN 60529 and is designed for a 100 per cent duty cycle. The unit operates on a mains supply of 220 to 240 volts; for locations outside the European mains supply, a 100 to 120-volt version is available on request.Documentation and ConformityThe unit comes with its own EU Declaration of Conformity available for download, as well as a data sheet in PDF format. The operating instructions cover not only this drive unit but also the ‘control’ variant of the T-25 easy-clean series and are available in 14 languages, ranging from German and English to Chinese, Thai and Korean. This means that the same set of instructions can be used at multiple workstations in locations with an international workforce.Typical applicationsThe wide speed range and the ‘easy-clean’ cleaning system make the unit particularly attractive in situations where there are frequent changes between different samples.Homogenisation of medical and pharmaceutical samples with frequent product changesEmulsification of cosmetic formulations on a laboratory scaleSuspending paints and coatingsDispersing under vacuum or pressure in conjunction with an IKA laboratory reactorSelection guide: digital or control, single unit or set?If you do not require temperature measurement, this digital drive unit is a good choice. If the sample temperature needs to be monitored during dispersion – for example, with heat-sensitive formulations – the T 25 easy clean control ULTRA-TURRAX is a better option; it measures temperatures between 0 and 125 degrees Celsius via an RFID-enabled tool. If you do not yet own a dispersing tool, the T 25 easy clean digital Solution saves you the trouble of selecting a separate tool; the set comes complete with the tool, stand and cross-coupling. For more compact applications with Wi-Fi connectivity and smaller volumes, the T 25 mini control ULTRA-TURRAX is also available; for larger volumes requiring higher performance, the T 25 digital ULTRA-TURRAX is the ideal choice.Technical detailsThe following table summarises the key specifications for the drive, operation and connections, as specified by IKA for the digital version of the T 25 easy clean series.Motor power input / output500 W / 400 WProcessable volume (H₂O)1 to 2,000 mlMax. viscosity5,000 mPasSpeed range3,000 to 25,000 rpm, continuously variable (2% deviation)Speed displayLEDMotor typebrushless, direct currentNoise level without tools70 dB(A)Boom diameter / boom length13 mm / 160 mmTimerYes, LED displayPermissible duty cycle100 %Permissible ambient temperature / humidity5 to 40 °C / 80 %Protection classIP 30 in accordance with DIN EN 60529USB interfaceMicro-USBPower rating220 to 240 V, 50/60 Hz, 500 W (alternative voltage option: 100 to 120 V)Dimensions (W x H x D)89 x 270 x 161 mmWeight3 kgContentsT 25 easy clean digital ULTRA-TURRAX drive unitUSB cable, USB A to Micro-B, 2 mA dispersing tool is not included in the scope of delivery and must be selected separately to suit the application.Regulatory informationThis device is an electrical appliance within the meaning of the German Electrical and Electronic Equipment Act (ElektroG). The WEEE registration number of the manufacturer, IKA, is DE 66784213. Information on the return of end-of-life equipment can be found on our Environment and Disposal page.Warranty and procurement serviceThe IKA manufacturer’s warranty applies to the T 25 easy clean digital ULTRA-TURRAX: 2 years, extended to 3 years upon registration at ika.com/register within 90 days of purchase. For dispersing tools, stands and other accessories, our procurement service will put together the appropriate set to complement the unit.

IKA explicitly specifies the S 25 EC - C - 25 F (0025007215) for dispersion applications in the cosmetics industry. The tool, made from AISI 316L and ceramic, has a stator diameter of 25 mm, processes batches from 100 to 2,000 ml and is compatible exclusively with the T 25 easy clean digital and T 25 easy clean control drives.Cleaning according to the ‘easy-clean’ principleThe name ‘easy clean’ describes the mechanism: when the clamp is turned and lowered, the shaft and rotor drop until the entire rotor emerges from the stator. The shaft tube can then be completely rinsed from the inside as well.Ceramic plain bearings instead of ball bearingsA ceramic plain bearing is used. AISI 316L and ceramic come into contact with the medium; the pH range is 2 to 13. The tool is suitable for solvents and abrasive substances; the maximum operating temperature is 180 °C. It can be sterilised using any method.Particle size specificationsThe rotor has a diameter of 18 mm, and the gap to the stator is 0.5 mm. At 25,000 rpm, a circumferential speed of up to 23.6 m/s is achieved. The final particle size is between 5 and 25 µm for suspensions and between 1 and 5 µm for emulsions. The immersion depth is 35 to 150 mm, and the installation length is 191 mm.Further easy-clean toolsFrom the same range, we stock the S 25 EC - C - 25 G and, with a temperature sensor, the S 25 EC - T - C - 25 G. For operation on the drive, IKA offers the T 25 easy-clean digital Solution set.Typical applicationsDispersing in the cosmetics industry, batches from 100 to 2,000 mlEmulsification with final particle sizes of 1 to 5 µmBatch changeover with internal flushing of the shaft tubeMedia containing solvents or abrasive componentsTechnical detailsWorking range (H2O)0.1 to 2 lStator diameter25 mmRotor diameter18 mmStator/rotor gap width0.5 mmMax. permissible speed25,000 rpmMaximum circumferential speed23.6 m/sPenetration depth35 to 150 mmInstallation length191 mmBearing and sealCeramic plain bearingsMaterials in contact with the productAISI 316L, ceramicpH range2 to 13Suitable for solventsYesSuitable for abrasive substancesYesMax. operating temperature180 °CSterilisabilityall methodsFinal particle size of suspensions5 to 25 µmFinal particle size (emulsions)1 to 5 µmWeight0.4 kgScope of delivery1 x IKA S 25 EC - C - 25 F dispersing tool (single tool)The drive is not included in the Scope of delivery.Individual requirements and procurement serviceIf you require the tool to be supplied together with the appropriate drive unit, do you need a second tool for changing, or guidance on selecting the correct geometry? We will put together the right combination for your application via our procurement service.
