IKA T 50 digital ULTRA-TURRAX disperser, 0.25 to 30 l, up to 10,000 rpm, 0003787000

The IKA S 50 N - G 45 G dispersing tool represents a high-purity and extremely powerful fluid-mechanical system solution for the professional comminution, homogenisation and suspension of sample media on a laboratory and pilot-plant scale. This precision-manufactured rotor-stator system has been specifically validated for use with the high-performance IKA dispersing drives of the ULTRA-TURRAX T 50 series. In complex processes within the chemical industry, food analysis, cosmetics manufacturing or biotechnology, the rapid disruption and mixing of coarse sample structures is the primary criterion for producing homogeneous suspensions or stable emulsions in a gentle and time-efficient manner for subsequent process or analytical steps. Fluid-mechanical comminution through optimised rotor-stator geometry The process-engineering heart of the unit is the generator in the tried-and-tested G version (Coarse). The perfectly matched geometry of the rotor and stator generates extremely high mechanical impact, cutting and shear forces in the transient shear gap, whilst maintaining a high axial flow rate. This mechanical kinetics is ideally designed to capture, disintegrate and homogenise lumpy samples, agglomerates, powders or viscous liquid-liquid phases in a flash. The open design of the generator head ensures excellent circulation of the medium, which minimises thermal hotspots in the sample vessel in a way that is gentle on the material and ensures process reliability. Material-related inertness and complete sterilisability The materials science design of the dispersing rod is consistently optimised for maximum chemical resilience and absolute freedom from contamination. All functional elements in contact with the medium are made of high-purity, stainless steel grade 1.4404 (AISI 316L). An extremely low-friction and wear-resistant PTFE bearing system is used for the shaft bearing. This combination of materials allows for continuous use in aggressive acids, alkalis and organic solvents. To ensure a sterile sampling environment and to completely prevent cross-contamination in multi-user operations, the entire tool can be easily sterilised in an autoclave or cleaned gently with standard disinfectants. Process reliability and flexible system integration The mechatronic system architecture guarantees safe and vibration-free power transmission even at maximum speeds of up to 10,000 revolutions per minute. The dispersing shaft can be quickly secured in the T 50 digital drive via the standardised connection without the need for tools. Thanks to the generous immersion depth of up to 250 mm and the fluid-mechanical geometry, the tool is certified for a wide working volume ranging from 0.5 to 20 litres (based on water). This offers laboratory managers and industrial users maximum flexibility when scaling up processes from research to pilot plant scale. Technical details Metrology & Dispersion Specifications Tool type: Rotor-stator dispersing tool Model designation: S 50 N - G 45 G Operating range (volume range for H₂O): 0.5 to 20 litres Generator version: G (Coarse) Maximum speed range: 10,000 rpm Maximum peripheral speed: approx. 18.8 m/s Construction, materials & geometry Materials in contact with the medium: Stainless steel 1.4404 (AISI 316L), PTFE Stator diameter: 45 mm Rotor diameter: 36 mm Shear gap (distance): approx. 0.5 mm Minimum immersion depth: 70 mm Max. immersion depth: 250 mm Shaft diameter: 30 mm Overall length: 290 mm Operating conditions & cleaning Solvent resistance: Yes (universal chemical resistance) Cleaning: Autoclavable (up to 121 degrees Celsius) and hot-air sterilisable (up to 180 degrees Celsius) Bearing type: PTFE plain bearing (shaft-guided, low-maintenance) Contents 1 x IKA S 50 N - G 45 G dispersing tool (MPN: 0008003000) 1 x Operating instructions / Quality certificate Important note: The required dispersing drive (e.g. IKA ULTRA-TURRAX T 50 digital), stand fixtures, cross-sockets and sample vessels are not included in the standard scope of delivery and must be configured separately. Individual requirements & accessories To get the most out of the IKA S 50 N - G 45 G tool, we recommend using it with the original ULTRA-TURRAX T 50 digital dispersing drive. To ensure a safe and vibration-free setup at your laboratory workstation, our range includes suitable telescopic stands (R 2722 or R 2723), robust cross-sockets (R 271) and practical vessel holders (RH 5). Should you wish to process samples requiring finer final homogenisation, we also offer alternative IKA generator heads with medium (M) or fine (F) toothing. For the regular replacement of wear parts, we stock original PTFE replacement bearings. Please use our technical procurement service to put together your complete homogenisation system.

The IKA S 50 N - G 45 G - ST dispersing tool represents a high-purity and extremely powerful fluid-mechanical system solution for the professional comminution, homogenisation and suspension of demanding sample media on a laboratory and pilot-plant scale. This precision-manufactured rotor-stator system has been specifically validated for use with the high-performance IKA dispersing drives of the ULTRA-TURRAX T 50 series. In complex processes within the pharmaceutical processing industry, food analysis, biotechnology or pulp research, the disruption of viscous, fibrous or elastic sample structures is the primary criterion for producing homogeneous suspensions in a gentle and time-efficient manner for subsequent analytical steps. Fluid-mechanical comminution via sawtooth geometry The process-engineering heart of the tool is the generator in a special ST (Saw Tooth) design. The distinctive geometry of the saw teeth on the rotor and stator generates extremely high mechanical impact, cutting and shear forces in the transient shear gap. This mechanical kinetics is ideally designed to cut and disintegrate fibrous matrices – such as tissue structures, plant parts, tobacco, paper and wood pulps, as well as tough plastics or viscous emulsions – in a flash. Uncontrolled wrapping of fibres around the shaft is prevented by the flow-optimised tooth arrangement, ensuring gentle handling of the material and process reliability. Material-related inertness and uncompromising sterilisability The materials science design of the dispersing rod is consistently optimised for maximum chemical resilience and absolute freedom from contamination. All functional elements in contact with the medium are made of high-purity, stainless steel grade 1.4404 (AISI 316L). The shaft is supported by an extremely low-friction and wear-resistant PTFE bearing system. This combination of materials allows for continuous use in aggressive acids, alkalis and organic solvents. To ensure a sterile sampling environment and to completely rule out cross-contamination in multi-user operation, the entire tool can be easily sterilised in an autoclave or cleaned gently with standard disinfectants. Process reliability and convenient system integration The mechatronic system architecture guarantees safe and vibration-free power transmission even at maximum speeds of up to 10,000 revolutions per minute. The dispersing shaft can be quickly and tool-free secured in the T 50 digital drive via the standardised connection. Thanks to the generous immersion depth of up to 250 mm and the fluid-mechanical geometry, the tool is certified for a wide working volume ranging from 0.5 to 20 litres (based on water). This offers laboratory managers and industrial users maximum flexibility when scaling up processes from research to pilot plant scale. Technical details Metrology & Dispersion Specifications Tool type: Rotor-stator dispersing tool Model designation: S 50 N - G 45 G - ST Operating range (volume range for H₂O): 0.5 to 20 litres Generator design: G (Coarse) with ST geometry (sawtooth) Maximum speed range: 10,000 rpm Maximum peripheral speed: approx. 18.8 m/s Design, materials & geometry Materials in contact with the medium: Stainless steel 1.4404 (AISI 316L), PTFE Stator diameter: 45 mm Rotor diameter: 36 mm Shear gap (distance): approx. 0.5 mm Minimum immersion depth: 70 mm Max. immersion depth: 250 mm Shaft diameter: 30 mm Overall length: 290 mm Operating conditions & cleaning Solvent resistance: Yes (universal chemical resistance) Cleaning: Autoclavable (up to 121 degrees Celsius) and hot-air sterilisable (up to 180 degrees Celsius) Bearing type: PTFE plain bearing (shaft-guided, low-maintenance) Contents 1 x IKA S 50 N - G 45 G - ST dispersing tool (MPN: 0008039500) 1 x Operating instructions / Quality certificate Important note: The required dispersing drive (e.g. IKA ULTRA-TURRAX T 50 digital), stand fixtures, cross-sockets and sample vessels are not included in the standard scope of delivery and must be configured separately. Individual requirements & accessories To get the most out of the IKA S 50 N - G 45 G - ST tool, we recommend using it with the original ULTRA-TURRAX T 50 digital dispersing drive. To ensure a safe and vibration-free setup at your laboratory workstation, our range includes suitable telescopic stands (R 2722 or R 2723), robust cross-sockets (R 271) and practical vessel holders (RH 5). Should you wish to process samples requiring finer final homogenisation, we also offer alternative IKA generator heads with medium (M) or fine (F) toothing. For the regular replacement of wear parts, we stock original PTFE replacement bearings. Please use our technical procurement service to put together your complete homogenisation system.

Narrow gap, large capacity: The S 50 N - G 45 M (0008003300) operates with a gap of 0.25 mm between the rotor and stator and processes volumes of 0.5 to 15 l. The stator measures 45 mm, the rotor 40.5 mm. It is driven by the T 50 digital.Bearings and materialsThe shaft is mounted in a PTFE split-ring bearing. Only PTFE and AISI 316L come into contact with the product. The unit is suitable for solvents and abrasive substances, with a pH range of 2 to 13. The short-term operating temperature is up to 180 °C, and it may be sterilised using any method.Speed, fineness and dimensionsA speed of 10,000 rpm is permitted, resulting in speeds of up to 21.2 m/s at the rotor. The final fineness ranges from 25 to 50 µm for suspensions and 5 to 20 µm for emulsions. The immersion depth ranges from 70 to 250 mm, the installation length is 298 mm, and the tool weighs 0.95 kg.Typical applicationsDispersing and emulsifying volumes from 0.5 to 15 lOperations with a narrow gap of 0.25 mmSuspensions with final particle sizes of 25 to 50 µmEmulsions with final particle sizes of 5 to 20 µmBatches containing solvents or abrasive componentsProcesses involving short-term temperatures of up to 180 °CTechnical detailsProcessable volume (H2O)0.5 to 15 lStator diameter45 mmRotor diameter40.5 mmStator/rotor gap width0.25 mmMax. permissible speed10,000 rpmMaximum circumferential speed21.2 m/sPenetration depth70 to 250 mmInstallation length298 mmBearingPTFE split ring bearingsMaterials in contact with the productPTFE, AISI 316LpH range2 to 13Suitable for solventsYesSuitable for abrasive substancesYesMax. operating temperature180 °C (for short periods)Sterilisabilityall methodsFinal particle size of suspensions25 to 50 µmFinal particle size of emulsions5 to 20 µmWeight0.95 kgScope of delivery1 x IKA S 50 N - G 45 M dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Same geometry with different bearing arrangementThe S 50 KD - G45M has the same geometry (45 mm stator, 40.5 mm rotor, 0.25 mm gap). It runs on a ball bearing with a PTFE seal, is rated up to 150 °C and may operate under vacuum down to 100 mbar. The S 50 N - G 45 F is made of the same materials, but has a 40 mm rotor, a 0.5 mm gap and 10 to 30 µm for suspensions. For those wishing to operate under vacuum down to 1 mbar, the S 50 KG - HH - G 45 M with a mechanical seal offers the same stator and rotor dimensions, also for 0.5 to 15 l.Individual requirements and procurement serviceShould the tool be supplied together with the T 50 digital drive? LT Laborhandel will put the combination together via its procurement service, including a second tool for changing.

With a stator diameter of 45 mm and an installation length of 290 mm, the S 50 N - G 45 F (0008003900) is designed for applications involving volumes in the litre range: the tool processes 0.25 to 10 l of water on the T 50 digital ULTRA-TURRAX. It weighs 0.929 kg, and the immersion depth ranges from 70 to 250 mm.Rotor, gap and final finenessThe rotor has a diameter of 40 mm, the gap to the stator measures 0.5 mm, and the peripheral speed is a maximum of 20.9 m/s. Final particle sizes of 10 to 30 µm are achieved for suspensions and 1 to 10 µm for emulsions. By way of comparison: the S 50 KG - HH - G 45 G specifies 40 to 100 µm, whilst the S 50 KG - HH - G 45 M specifies 25 to 50 µm for suspensions.Principle and limitationsAs with all ULTRA-TURRAX tools, the rotor draws in the medium and forces it radially through the slots in the stator. The shearing effect depends on the gap and the circumferential speed; for the S 50 N, G 45 F, these are 0.5 mm and up to 20.9 m/s.Bearings and materialsThe shaft runs in a PTFE split-ring bearing. The materials in contact with the product are PTFE and AISI 316L. The tool is suitable for solvents and abrasive substances; the pH range is from 2 to 13. Temperatures of up to 180 °C are permissible for short periods, and it can be sterilised using all methods.When another S-50 tool is recommendedThe ball bearing versions with a carbide mechanical seal allow for vacuum down to 1 mbar and pressure up to 6 bar. The S 50 KD - G 45 G ST is available as an autoclavable version with ball bearings.Typical applicationsDispersing and emulsifying on a scale of 0.25 to 10 lMedia containing solvents in the pH range 2 to 13Batches containing abrasive solidsProcessing of the tool between runs using all sterilisation methodsTechnical detailsWorking range (H2O)0.25 to 10 lStator diameter45 mmRotor diameter40 mmStator/rotor air gap width0.5 mmMaximum circumferential speed20.9 m/sImmersion depth70 to 250 mmInstallation length290 mmBearing and sealShaft in PTFE split-ring bearingMaterials in contact with the productPTFE, AISI 316LpH range2 to 13Suitable for solventsYesSuitable for abrasive substancesYesMax. operating temperature180 °CSterilisabilityall methodsFinal particle size of suspensions10 to 30 µmFinal particle size (emulsions)1 to 10 µmWeight0.929 kgScope of delivery1 x IKA S 50 N - G 45 F dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceFor a second drive unit, a different version of the tool, or enquiries regarding compatibility with your existing equipment, please contact the LT Laborhandel procurement service.

The S 50 KG - HH - G 45 G (0008003200) can process up to 20 l of water in a single batch; the minimum volume is 0.5 l. The shaft is mounted on ball bearings; the single-acting mechanical seal consists of carbide against carbide, and operation under vacuum is possible. The T 50 digital serves as the drive.Seal and pressure rangeThe carbide seal and the design allow for vacuum down to 1 mbar and pressure up to 6 bar. Materials in contact with the product include FFPM, carbide (WC) and AISI 316L. The tool is solvent-resistant, with a pH range of 2 to 13. It can be sterilised using wet chemical methods, and the short-term operating temperature is up to 150 °C.Dimensions and precisionThe rotor draws in the medium and forces it radially through the stator slots. With a rotor diameter of 36 mm and a circumferential speed of up to 18.8 m/s, these figures are lower than those of the S 50 N - G 45 F, which has a diameter of 40 mm and a speed of 20.9 m/s. The stator measures 45 mm. The immersion depth is 70 to 260 mm with an installation length of 300 mm; the unit weighs 0.552 kg. The final fineness is between 40 and 100 µm for suspensions and between 10 and 30 µm for emulsions.Comparison within the S-50 seriesThe S 50 KG - HH - G 45 M has the same design, but processes only 0.5 to 15 l and specifies narrower final fineness ranges of 25 to 50 µm (suspensions) and 5 to 20 µm (emulsions). Those working without a vacuum who wish to achieve finer dispersion will find the S 50 N - G 45 F, with PTFE bearings, suitable for 10 to 30 µm.Typical applicationsDispersing and emulsifying volumes of 0.5 to 20 lOperations under vacuum down to 1 mbarSolvent-based processesProcesses at pressures up to 6 barTechnical detailsWorking range (H2O)0.5 to 20 lStator diameter45 mmRotor diameter36 mmMax. circumferential speed18.8 m/sImmersion depth70 to 260 mmInstallation length300 mmBearing and sealBall bearing, single-acting mechanical seal (carbide/carbide)Materials in contact with the productFFPM, WC / AISI 316LpH range2 to 13Suitable for solventsYesMax. operating temperature150 °CSterilisabilitywet chemicalVacuum1 mbarMax. pressure6 barFinal fineness of suspensions40 to 100 µmFinal fineness of emulsions10 to 30 µmWeight0.552 kgScope of delivery1 x IKA S 50 KG - HH - G 45 G dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceIf you require the tool to be supplied together with the appropriate drive unit, do you need a second tool for changing, or guidance on selecting the correct geometry? LT Laborhandel will put together the right combination for your application via its procurement service.

The ‘ST’ suffix in the name distinguishes the S 50 KG - HH - G 45 G - ST (0010000648) from the version without ‘ST’, the S 50 KG - HH - G 45 G, which has the same stator and rotor dimensions (45 and 36 mm). The unit processes volumes of 0.5 to 20 l and is driven by the T 50 digital drive.Mechanical seal for vacuumThe shaft is mounted on ball bearings; the single-acting mechanical seal consists of tungsten carbide against tungsten carbide. Operation under vacuum down to 1 mbar is possible; the pressure may reach up to 6 bar. Materials in contact with the product are FFPM, tungsten carbide (WC) and AISI 316L. The tool is solvent-resistant, with a pH range of 2 to 13. Sterilisation is carried out using wet chemical methods, and the short-term operating temperature is up to 150 °C.Rotor, fineness and dimensionsThe rotor measures 36 mm and, at the permissible speed, reaches up to 18.8 m/s at the circumference. The final fineness ranges from 40 to 100 µm for suspensions and from 10 to 30 µm for emulsions. The immersion depth is 70 to 260 mm, and the installation length is 300 mm. The tool weighs 0.576 kg.Typical applicationsDispersing and emulsifying volumes of 0.5 to 20 lOperations under vacuum down to 1 mbarProcesses with overpressure up to 6 barSuspensions with final particle sizes of 40 to 100 µmSolvent-based processesTechnical detailsProcessable volume (H2O)0.5 to 20 lStator diameter45 mmRotor diameter36 mmMax. circumferential speed18.8 m/sImmersion depth70 to 260 mmInstallation length300 mmBearing and sealBall bearing, single-acting mechanical seal (carbide/carbide)Materials in contact with the productFFPM, WC / AISI 316LpH range2 to 13Suitable for solventsYesMax. operating temperature150 °C (for short periods)Sterilisabilitywet chemicalVacuum1 mbarMax. pressure6 barFinal fineness of suspensions40 to 100 µmFinal fineness of emulsions10 to 30 µmWeight0.576 kgScope of delivery1 x IKA S 50 KG - HH - G 45 G - ST dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Rotor sizes in the S 50 seriesThe S 50 KD - G45G ST is also an ST version for 0.5 to 20 l, but has a 38 mm rotor, 19.9 m/s and operates under vacuum down to 100 mbar. The S 50 KD - G45G also has the same stator, the same rotor and the same operating range as described here, and is also suitable for suspensions with particle sizes of 40 to 100 µm. The S 50 KG - HH - G 45 M also features a mechanical seal and operates under vacuum down to 1 mbar, but has a 40.5 mm rotor, a capacity of 0.5 to 15 l and a particle size range of 25 to 50 µm for suspensions.Individual requirements and procurement serviceWhether you need a second tool for changing parts, a T 50 digital drive or assistance with geometry: LT Laborhandel can sort this out via its procurement service.

The final fineness of the S 50 KG - HH - G 45 M (0008003500) ranges from 25 to 50 µm for suspensions and from 5 to 20 µm for emulsions. With a 40.5 mm rotor in a 45 mm stator, the difference compared with the sister tool, the S 50 KG - HH - G 45 G, is clearly evident: There, the particle sizes range from 40 to 100 µm and 10 to 30 µm, whilst the working volume extends to 20 l instead of 15.Geometry and rotational speedThe rotor draws in the medium and forces it radially through the stator slots. With a rotor diameter of 40.5 mm, the peripheral speed reaches 21.2 m/s; the G tool, with a 36 mm rotor, achieves 18.8 m/s. The immersion depth is 70 to 250 mm, the installation length is 300 mm, and the tool weighs 0.52 kg. Working range 0.5 to 15 l, compatible with the T 50 digital drive.Ball bearing and carbide sealThe shaft is mounted on ball bearings; the single-acting mechanical seal consists of carbide against carbide. Operation under vacuum down to 1 mbar and at pressures up to 6 bar is possible. Materials in contact with the product include FFPM, tungsten carbide (WC) and AISI 316L; the tool is solvent-resistant. The pH range is 2 to 13, the short-term operating temperature is up to 150 °C, and it can be sterilised using wet chemical methods.Alternatives in the S-50 rangeThe S 50 N - G 45 F (0.25 to 10 l), which operates without the need for a vacuum, features a PTFE slotted ring bearing and achieves a particle size of 10 to 30 µm for suspensions and 1 to 10 µm for emulsions. The autoclavable ball-bearing version is the S 50 KD - G 45 G ST (0.5 to 20 l, up to 10,000 rpm).Typical applicationsDispersing and emulsifying 0.5 to 15 lOperations under vacuum down to 1 mbarProcesses involving solventsApplications requiring final particle sizes of 5 to 20 µm in emulsionsTechnical detailsWorking range (H2O)0.5 to 15 lStator diameter45 mmRotor diameter40.5 mmMaximum circumferential speed21.2 m/sImmersion depth70 to 250 mmInstallation length300 mmBearing and sealBall bearing, single-acting mechanical seal (carbide/carbide)Materials in contact with the productFFPM, WC / AISI 316LpH range2 to 13Suitable for solventsYesMax. operating temperature150 °CSterilisabilitywet chemicalVacuum1 mbarMax. pressure6 barFinal fineness of suspensions25 to 50 µmFinal fineness of emulsions5 to 20 µmWeight0.52 kgScope of delivery1 x IKA S 50 KG - HH - G 45 M dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceDo you also need the drive unit, a replacement tool or help choosing between the different models? LT Laborhandel sources the components via its procurement service and tailors them to your specific requirements.

The S 50 KG - HH - G 45 F (0008004100) handles 0.25 to 10 l with a 45 mm stator and a 40 mm rotor. The shaft is mounted on ball bearings; the single-acting mechanical seal consists of carbide against carbide. The T 50 digital serves as the drive.Vacuum, pressure and mediaWith the mechanical seal, the unit is designed for vacuum down to 1 mbar and pressure up to 6 bar. Materials in contact with the product include FFPM, tungsten carbide (WC) and AISI 316L. IKA describes it as solvent-resistant. The maximum operating temperature is 150 °C; sterilisation is carried out using wet chemical methods.Dimensions and final finenessThe immersion depth ranges from 70 to 250 mm, whilst the installation length is 290 mm. At a maximum peripheral speed of 20.9 m/s, the tool achieves final finenesses of 10 to 30 µm for suspensions and 1 to 10 µm for emulsions. It weighs 0.51 kg. At 40 mm, the rotor is larger than that of the S 50 KG - HH - G 45 G (36 mm), and the peripheral speed is correspondingly higher than its 18.8 m/s.The same dimensions without a mechanical sealWith the same operating range and final particle size, but with PTFE bearings instead of a mechanical seal, there is the S 50 N - G 45 F is available. The immersion depth (70 to 250 mm) and overall length (290 mm) are the same as for this tool. Those working under vacuum should stick with the KG version.Larger applicationsThe S 50 KG - HH - G 45 G, with a 36 mm rotor and a final fineness of 40 to 100 µm (suspensions), processes volumes of up to 20 l. The S 50 KG - HH - G 45 M covers volumes from 0.5 to 15 l and specifies 25 to 50 µm for suspensions and 5 to 20 µm for emulsions.Typical applicationsDispersing and emulsifying in batches of 0.25 to 10 lOperations under vacuum down to 1 mbarProcesses at pressures up to 6 barBatches containing solventsSamples where the tool is sterilised using wet chemical methodsTechnical detailsWorking volume (H2O)0.25 to 10 lStator diameter45 mmRotor diameter40 mmMaximum circumferential speed20.9 m/sImmersion depth70 to 250 mmInstallation length290 mmBearing and sealBall bearing, single-acting mechanical seal (carbide/carbide)Materials in contact with the productFFPM, WC / AISI 316LSuitable for solventsYesMax. operating temperature150 °CSterilisabilitywet chemicalVacuum1 mbarMax. pressure6 barFinal fineness of suspensions10 to 30 µmFinal fineness of emulsions1 to 10 µmWeight0.51 kgScope of delivery1 x IKA S 50 KG - HH - G 45 F dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceLT Laborhandel can supply the T 50 digital drive and a second tool for changing on request. The procurement service will assist with selecting the correct geometry.

The operating range of the S 50 KD - G45G (0010000629) is from 0.5 to 20 l of water. The tool has a stator diameter of 45 mm and a rotor diameter of 36 mm; the air gap is 0.5 mm. It is operated on the T 50 digital drive.Ball bearing with PTFE sealThe shaft runs in a ball bearing with a PTFE seal and an FFKM O-ring. Materials in contact with the product are FFPM, PTFE and AISI 316L. The tool is suitable for solvents; the pH range is from 2 to 13. The maximum operating temperature is 150 °C; it may be used under vacuum down to 100 mbar. IKA specifies the tool as autoclavable.Dimensions and finenessThe immersion depth is between 70 and 260 mm; the installation length is 300 mm. At a maximum of 10,000 rpm, the rotor circumference reaches 18.8 m/s. The final fineness ranges from 40 to 100 µm for suspensions and from 10 to 30 µm for emulsions. The tool weighs 0.9855 kg.Suitable driveIKA refers to this tool as the T 50 digital. At 18.8 m/s, the peripheral speed is lower than the 20.9 m/s of the S 50 N - G 45 F, which has a 40 mm rotor.Differences from similar modelsThe S 50 KG - HH - G 45 G operates within the same working range and has the same rotor dimensions. It features a carbide mechanical seal and is designed for vacuums down to 1 mbar and pressures up to 6 bar. For finer results with a narrower gap of 0.25 mm and flow rates from 0.5 to 15 l, the S 50 KD - G45M is available.Typical applicationsDispersing and emulsifying in batches of 0.5 to 20 lOperations under vacuum down to 100 mbarBatches containing solventsBatches where the tool is autoclavedTechnical detailsWorking range (H2O)0.5 to 20 lRecommended working range500 to 20,000 mlStator diameter45 mmRotor diameter36 mmStator/rotor gap width0.5 mmMax. permissible speed10,000 rpmMaximum circumferential speed18.8 m/sPenetration depth70 to 260 mmInstallation length300 mmBearing and sealBall bearing with PTFE seal and FFKM O-ringMaterials in contact with the productFFPM, PTFE, AISI 316LpH range2 to 13Suitable for solventsYesMax. operating temperature150 °CSterilisabilityAutoclavableVacuum100 mbarFinal particle size of suspensions40 to 100 µmFinal particle size of emulsions10 to 30 µmWeight0.9855 kgScope of delivery1 x IKA S 50 KD - G45G dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceLT Laborhandel can source the T 50 digital drive, a second tool for changing, or advice on geometry on request. The procurement service will put together the right combination for your application.

The S 50 KD - G 45 G ST (0010000632) is rated for 10,000 rpm; the tool is autoclavable and permits a vacuum of 100 mbar. Stator 45 mm, rotor 38 mm, working range 0.5 to 20 l. IKA specifies the T 50 digital as the drive unit.Speed limitAt 10,000 rpm, the maximum permissible speed is lower than the 25,000 rpm of the S-25 tools. With a rotor diameter of 38 mm, this results in a circumferential speed of 19.9 m/s. The rotor draws in the medium and forces it radially through the stator slots; the stator diameter is 45 mm.GeometryThe gap width is 0.5 mm; at maximum speed, this results in a circumferential speed of 19.9 m/s. The immersion depth ranges from 70 to 260 mm; the installation length is 300 mm; the tool weighs 0.71 kg. The final particle size is between 40 and 100 µm for suspensions and between 10 and 30 µm for emulsions.Bearing, seal and designThe shaft is mounted in a ball bearing with a PTFE seal and an FFKM O-ring. Materials in contact with the product are AISI 316L, PTFE and FFPM. The tool is suitable for solvents and designed for operating temperatures up to 150 °C. It is autoclavable; the ball bearing is excluded from sterilisation.Differences from the KG instrumentsThis version achieves the same final fineness values as the S 50 KG - HH - G 45 G within the same operating range of 0.5 to 20 l. Differences lie in the seal, rotor and sterilisation: It features a carbide mechanical seal capable of withstanding a vacuum down to 1 mbar and pressure up to 6 bar; the rotor measures 36 mm; and sterilisation is carried out using wet chemical methods only. The S 50 N, G 45 F operates with a PTFE slotted ring bearing.Typical applicationsDispersing and emulsifying volumes from 0.5 to 20 lProcesses in which the tool is autoclavedWork under vacuumSolvent-based applicationsTechnical detailsWorking range (H2O)0.5 to 20 lStator diameter45 mmRotor diameter38 mmStator/rotor air gap width0.5 mmMaximum permissible speed10,000 rpmMaximum circumferential speed19.9 m/sPenetration depth70 to 260 mmInstallation length300 mmBearing and sealBall bearing with PTFE seal and FFKM O-ringMaterials in contact with the productFFPM, PTFE, AISI 316LpH range2 to 13Suitable for solventsYesMax. operating temperature150 °CSterilisabilityAutoclavable, all methods except ball bearingsVacuum100 mbarFinal particle size of suspensions40 to 100 µmFinal fineness of emulsions10 to 30 µmWeight0.71 kgScope of delivery1 x IKA S 50 KD - G 45 G ST dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceFor a second drive unit, a different version of the tool, or enquiries regarding compatibility with your existing equipment, please contact the LT Laborhandel procurement service.

On the S 50 KD - G45M (0010000630), the gap between the rotor and the stator is 0.25 mm; on the S 50 KD - G45G, it is 0.5 mm. The stator measures 45 mm, the rotor 40.5 mm, and the machining capacity is 0.5 to 15 l. The tool is driven by the T 50 digital drive.Ball bearing with PTFE sealThe shaft runs in a ball bearing with a PTFE seal and an FFKM O-ring. Materials in contact with the product are FFPM, PTFE and AISI 316L. The pH range is from 2 to 13; the unit is suitable for use with solvents. It may be used under vacuum down to 100 mbar; the maximum operating temperature is 150 °C. IKA specifies it as autoclavable.Dimensions and precisionThe immersion depth is 70 to 260 mm, and the installation length is 300 mm. A speed of 10,000 rpm is permitted, with the rotor reaching speeds of up to 21.2 m/s. The final fineness ranges from 25 to 50 µm for suspensions and from 5 to 20 µm for emulsions. The tool weighs 0.645 kg, and the recommended batch size is 500 to 15,000 ml.Comparison within the S-50 seriesThe S 50 KD - G45G processes up to 20 l, has a 36 mm rotor and a 0.5 mm gap, and specifies a particle size of 40 to 100 µm for suspensions. The S 50 N - G 45 M. For those wishing to operate under vacuum down to 1 mbar, the S 50 KG - HH - G 45 M offers a version with a carbide mechanical seal.Typical applicationsDispersing and emulsifying in batches of 0.5 to 15 lWork with a narrow gap of 0.25 mmBatches containing solventsWorking under vacuum down to 100 mbarSamples where the tool is autoclavedTechnical detailsWorking range (H2O)0.5 to 15 lRecommended working range500 to 15,000 mlStator diameter45 mmRotor diameter40.5 mmStator/rotor gap width0.25 mmMax. permissible speed10,000 rpmMax. circumferential speed21.2 m/sPenetration depth70 to 260 mmInstallation length300 mmBearing and sealBall bearing with PTFE seal and FFKM O-ringMaterials in contact with the productFFPM, PTFE, AISI 316LpH range2 to 13Suitable for solventsYesMax. operating temperature150 °CSterilisabilityAutoclavableVacuum100 mbarFinal particle size of suspensions25 to 50 µmFinal particle size of emulsions5 to 20 µmWeight0.645 kgScope of delivery1 x IKA S 50 KD - G45M dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceWhether you need a second tool for changing, the T 50 digital drive or guidance on selecting the right geometry: LT Laborhandel can source these items and offer advice through its procurement service.

The S 50 KD - G45F (0010000631) is designed for batch sizes ranging from 0.25 to 10 l. The stator measures 45 mm, the rotor 40 mm; at 10,000 rpm, speeds of up to 20.9 m/s are achieved at the rotor circumference. IKA specifies the T 50 digital as the drive.Ball bearing with PTFE sealThe shaft runs in a ball bearing with a PTFE seal and an FFKM O-ring. Materials in contact with the product are FFPM, PTFE and AISI 316L. The pH range is 2 to 13; solvents are permitted. Under vacuum, the tool may be used down to 100 mbar; the maximum operating temperature is 150 °C. IKA states that it is autoclavable.Gap, fineness and dimensionsThe gap between the rotor and stator is 0.5 mm wide. The final fineness ranges from 10 to 30 µm for suspensions and from 1 to 10 µm for emulsions. The immersion depth is 70 to 260 mm with an installation length of 300 mm; batch sizes of 250 to 10,000 ml are recommended. The tool weighs 0.658 kg.Typical applicationsDispersing and emulsifying in batches of 0.25 to 10 lSuspensions with final particle sizes of 10 to 30 µmEmulsions with final particle sizes of 1 to 10 µmOperations under vacuum down to 100 mbarBatches containing solventsSamples where the tool is autoclavedTechnical detailsProcessable volume (H2O)0.25 to 10 lStator diameter45 mmRotor diameter40 mmStator/rotor gap width0.5 mmMax. permissible speed10,000 rpmMaximum circumferential speed20.9 m/sPenetration depth70 to 260 mmInstallation length300 mmBearing and sealBall bearing, PTFE seal, FFKM O-ringMaterials in contact with the productFFPM, PTFE, AISI 316LpH range2 to 13Suitable for solventsYesMax. operating temperature150 °CSterilisabilityAutoclavableVacuum100 mbarFinal particle size of suspensions10 to 30 µmFinal particle size of emulsions1 to 10 µmWeight0.658 kgScope of delivery1 x IKA S 50 KD - G45F dispersing tool (single tool)The T 50 digital drive is not included in the Scope of delivery.Same dimensions, different bearing arrangementThe S 50 N - G 45 F has the same stator, rotor and gap dimensions (45, 40 and 0.5 mm). It is made of PTFE and AISI 316L, has a specified operating temperature of 180 °C and an installation length of 290 mm with an immersion depth of 70 to 250 mm. The S 50 KG - HH - G 45 F also has a 45 mm stator and a 40 mm rotor, plus a mechanical seal and a vacuum rating of up to 1 mbar. The S 50 KD - G45M (0.5 to 15 l) has a narrower gap of 0.25 mm and a 40.5 mm rotor.Individual requirements and procurement serviceWhether you need a second tool to swap in, the T 50 digital drive or guidance on selecting the right geometry: LT Laborhandel can source the equipment and provide advice through its procurement service.

With the R 50 agitator shaft (0001689300), the T 50 digital disperser becomes a high-speed agitator. The shaft is fitted with a dissolver disc and is suitable for batches ranging from 0.25 to 30 l. IKA classifies it as suitable for applications requiring medium to high shear forces.Conversion of the T 50 digitalIKA describes the stirring shaft as a conversion kit that transforms the T 50 digital disperser into a high-speed stirrer. The drive remains the same, but the mixing element at the lower end of the shaft is different. The applications involve medium to high shear forces, specifically rapid mixing, dissolution and deagglomeration.Dissolver and safety cageThe R 1402 dissolver is included in the scope of delivery. A safety cage is fitted around the mixing element to ensure workplace safety. The permissible speed is 10,000 rpm, with a maximum peripheral speed of 23.6 m/s. The immersion depth ranges from 50 to 180 mm, and the installation length is 323 mm.Materials and LimitsMaterials in contact with the product are AISI 316L and AISI 304. The shaft is suitable for solvents and abrasive substances; the pH range is from 2 to 13. The maximum operating temperature is 150 °C. Dry running is permitted. The weight is 1.25 kg.Propeller design for lower shearIKA lists the R 1405 propeller design as an optional retrofit for the mixing head. It is intended for low to medium viscosity at low shear rates.Alternative with rotor and statorThose wishing to use the T 50 digital with stator geometry will find the S 50 N - G 45 F suitable for volumes of 0.25 to 10 l, or the S 50 KD - G45G for volumes of 0.5 to 20 l.Typical applicationsRapid mixing and dissolutionDeagglomerationApplications involving medium to high shear forcesBatches from 0.25 to 30 lWorking with solventsTechnical detailsOperating range (H2O)0.25 to 30 lRotor diameter40 mmMax. permissible speed10,000 rpmMaximum peripheral speed23.6 m/sPenetration depth50 to 180 mmInstallation length323 mmMaterials in contact with the productAISI 316L, AISI 304pH range2 to 13Suitable for solventsYesSuitable for abrasive substancesYesMax. operating temperature150 °CDry operationYesProtective cageFitted around the mixing elementWeight1.25 kgScope of delivery1 x IKA R 50 high-speed stirring shaft1 x Dissolver R 1402The T 50 digital drive is not included in the Scope of delivery.Individual requirements and procurement serviceLT Laborhandel can source the T 50 digital drive, the R 1405 propeller version and other accessories on request. The procurement service will put together the appropriate combination.

A four-bladed cutting blade acting as the rotor, a stator diameter of 65 millimetres, weighing 1.5 kilograms: the IKA S 50 N - W 65 SK is a cutting head for the T 50 digital and operates in batches of 1 to 10 l.What materials it cutsIKA describes the tool as suitable for comminuting fibrous, elastic-soft, soft-tough and moist-plastic materials. The final particle size ranges from 50 to 200 micrometres for suspensions and from 5 to 15 micrometres for emulsions.Design and durabilityThe shaft runs in a PTFE split-ring bearing. Materials in contact with the product are PTFE, AISI 316L and AISI 301. The tool is FDA-compliant, suitable for solvents and can be used in the pH range 2 to 13. Operating temperatures of up to 180 degrees Celsius are permissible for short periods; sterilisation may be carried out using any method.Rotational and immersion dataSpeeds of up to 10,000 rpm are permitted, resulting in a peripheral speed of 28.8 metres per second at the rotor circumference. The immersion depth is 80 to 250 millimetres. The tool is part of the T 50 digital drive system.Typical applicationsComminution of fibrous materialsGrinding of elastic-soft and soft-tough materialsShredding moist, plastic materialsBatches of 1 to 10 lProcesses involving solvents in the pH range 2 to 13Technical detailsStator diameter65 mmRotor diameter55 mmRotor shapefour-bladed cutting bladeProcessing volume (H2O)1 to 10 lMax. permissible rotational speed10,000 rpmMaximum peripheral speed28.8 m/sImmersion depth80 to 250 mmBearingPTFE slotted ring bearingsMaterial in contact with the productPTFE, AISI 316L, AISI 301pH range2 to 13Suitable for solventsYesMax. operating temperature (short-term)180 °CSterilisabilityall methodsFinal particle size of suspensions50 to 200 µmFinal particle size of emulsions5 to 15 µmFDA complianceYesWeight1.5457 kgScope of delivery1 x IKA S 50 N - W 65 SK cutting head dispersing tool (single tool)The drive is not included in the scope of delivery.Other tools for the T 50 digitalFor emulsifying and dispersing rather than cutting, LT Laborhandel stocks, amongst others, the S 50 N - G 45 F with a 45-millimetre stator diameter and the S 50 KD - G 45 G ST with a 38-millimetre rotor diameter for 0.5 to 20 l. The S 50 KG - HH - G 45 G also covers volumes up to 20 l.Selection guide: a comparisonToolStator / RotorWorking range (H2O)S 50 N - W 65 SK cutting head (this product)65 / 55 mm1 to 10 lS 50 N - G 45 F45 / 40 mm0.25 to 10 lS 50 KD - G45G ST45 / 38 mm0.5 to 20 lS 50 KG - HH - G 45 G45 / 36 mm0.5 to 20 lIndividual requirements and procurement serviceLT Laborhandel can source the T 50 digital and other instruments on request. The procurement service can assist with selection.

Maximum circulation, minimal air ingress: IKA jet mixing head S 50 N - W 80 SMK The IKA S 50 N - W 80 SMK (MPN 0008006300) is a highly specialised dispersing and mixing tool for the high-performance IKA T 50 digital drive. Whilst conventional dispersing tools are designed for maximum shear forces to break down materials, this jet mixing head (SMK) is designed for efficient mixing and suspension in large volumes ranging from 1 to 50 litres (based on water). The jet mixing principle The geometry of the SMK generates a strong axial flow (from top to bottom or bottom to top, depending on the orientation/direction of rotation). Suspension of powders: Solids are swept up from the bottom of the vessel by the directed liquid jet and distributed homogeneously throughout the liquid. No vortex effect: Unlike simple propeller agitators, the stator tube prevents the formation of a deep vortex. This ensures that no unwanted air is incorporated into the medium – a crucial advantage when producing sensitive emulsions or foaming media. Rapid mixing: Even in large beakers or small vessels (up to 50 litres), the Ø 80 mm stator head ensures rapid and complete circulation of the entire sample. High-quality construction (“N”) The unit is built for heavy-duty, continuous use in laboratories and pilot plants: Materials: All components that come into contact with the medium are made of high-quality stainless steel (AISI 316L). PTFE bearing (“N”): The tried-and-tested, highly chemically-resistant PTFE bearing ensures smooth operation and a long service life. Hygiene: The tool can be easily dismantled for thorough cleaning and is fully autoclavable at 121 °C. Areas of application Chemicals & Cosmetics: Mixing thickeners, powders or pigments into liquids without trapping air. Environmental analysis: Stirring of sediments or sludge samples in large containers. Food technology: Suspending solids in large volumes (e.g. milk powder, cocoa). Pilot plant/scale-up: Preparation of batches for subsequent production. Technical data Model: S 50 N - W 80 SMK (jet mixing head) Suitable for drive: IKA T 50 digital Working range (H₂O volume): 1 – 50 litres Stator diameter: 80 mm Rotor diameter: 50 mm Maximum permissible speed: 10,000 rpm Immersion depth: 140 – 350 mm Materials in contact with the medium: stainless steel (AISI 316L), PTFE Maximum permissible operating temperature: 180 °C Sterilisation methods: Autoclavable (121 °C) Weight: approx. 0.8 kg Contents of delivery 1 x IKA jet mixing head S 50 N - W 80 SMK (Note: The T 50 digital drive motor is not included and must be ordered separately!) Individual requirements & accessories Please note that to operate this tool, you will require the large T 50 digital dispersion drive as well as a very robust stand (e.g. telescopic stand R 2723), as enormous flow forces are generated at 50 litres and a diameter of 80 mm. Please contact our procurement service to put together your complete system.
